39
滑動式瑣碎食品整理盒
突起
角孔
蔬果箱
將箱門向面前側打開到底。
如圖將瑣碎食品整理滑動盒向上推後拆
下。
將箱門稍微往上扳後，再慢慢向外
拉開，讓箱門傾斜。
將蔬果箱向上取出。安裝時，請將箱子左右內側
突出部分向門框兩旁的凹入的框架插入，將蔬果
箱的邊緣架置在框架上固定。
蔬果保鮮室蔬果保鮮室
打開門，向前方取出。
安裝時，請將左右4處向門框兩旁的洞角插入固定。
滑動盒
薄滑動盒
突起
角孔
框
框
下層冷凍盒
拉開門。
如圖拉開薄滑動盒及滑動盒慢慢向外拉。
將里面兩處固定扣打開才可以取出抽屜用防凍卡。
冷凍盒向上取出。
安裝時，請將盒子突出部分向門框兩旁的洞角插入固定。
下層冷凍的不鏽鋼盒不能除卸。
已拆下抽屜門時已拆下抽屜門時
框
框
Ice Compartment
製冰室 /
Upper Moisturized Freezer 上層保濕冷凍室
Vegetable Compartment
When the pull-out door has been removed
下層保濕冷凍室下層保濕冷凍室
Lower Moisturized Freezer
Open the door, lift the case toward you.
To set the case, fit the 4 projections on its right and left
into the notches of the frame.
Fully open the door toward you and lift the
small vegetables case; as show in the figure.
Lift the front of the door toward you,
slowly pull it out and tilt the door.
Lift the vegetable case directly above. To install it,
insert the projections on the left and right back of the
vegetable case into the square hole of the frame and
set it so that the edge of the vegetable case rests on
the frame.
Frame
Frame
Frame
Frame
Corner holes
Corner holes
Vegetable case
Projection
Projection
Lower freezer case
Slimline slide case
Slide case
Small vegetable case
Open the door and pull out the slimline slide
case and the slide case.
Release 2 tabs located further inside of the slide case
to remove the freezer burn preventing cassette.
Pull straight up the lower freezer case.
To set the case, fit the 2 projections on its right and left into the corner holes on the frame.
Stainless steel tray of the lower freezer case is not detachable.
（繼續）
（Continue）
Vegetable Compartment
Independent Ice Compartment
蔬果保鮮室
Lower Moisturized Freezer
下層保濕冷凍室
Upper Moisturized Freezer
上層保濕冷凍室
獨立式製冰室
(HOW TO REMOVE PARTS)
保養方法
(卸除組件的方法)
(
卸除組件的方法)
HOW TO MAINTAIN
框
Frame
How To Maintain (how To Remove Parts) (Continue)
保養方法 (卸除組件的方法) （繼續）
保養
How To Maintain
R-X6000H_A4.indd 39R-X6000H_A4.indd 39 12/5/07 9:54:08 AM12/5/07 9:54:08 AM
To Next Page
