Monobloc system - YUTAKI M
Model Power supply Operation mode Z
max
(Ω)
RASM-3VNE
1~ 230V 50Hz
Without DHW tank heater 0.35
With DHW tank heater 0.22
RASM-4VNE
Without DHW tank heater 0.24
With DHW tank heater 0.17
RASM-5VNE
Without DHW tank heater 0.24
With DHW tank heater 0.17
RASM-6VNE
Without DHW tank heater 0.24
With DHW tank heater 0.17
RASM-4NE
3N~ 400V 50Hz
Without DHW tank heater -
With DHW tank heater 0.31
RASM-5NE
Without DHW tank heater -
With DHW tank heater 0.31
RASM-6NE
Without DHW tank heater -
With DHW tank heater 0.30
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
• The status of Harmonics for each model, regarding compliance with IEC 61000-3-2 and IEC 61000-3-12, is as follows:
Status regarding compliance with
IEC 61000-3-2 and IEC 61000-3-12
Models
Split system
Monobloc
system
Outdoor unit
Indoor unit
YUTAKI M
YUTAKI S YUTAKI S COMBI YUTAKI S80
Equipment complying with
IEC 61000-3-2
(*): Professional use
RAS-2WHVNP
RAS-2.5WHVNP
RAS-3WHVNP
RAS-4WHNPE (*)
RAS-5WHNPE (*)
RAS-6WHNPE (*)
RWM-2.0NE
RWM-2.5NE
RWM-3.0NE
RWM-4.0NE (3N~)
RWM-5.0NE (3N~)
RWM-6.0NE (3N~)
RWM-8.0NE
RWM-10.0NE
-
RWH-4.0NFE
RWH-5.0NFE
RWH-6.0NFE
RASM-4NE
RASM-5NE
RASM-6NE
Equipment complying with
IEC 61000-3-12
RAS-4WHVNPE
RAS-5WHVNPE
RAS-6WHVNPE
RWM-4.0NE (1~)
RWM-5.0NE (1~)
RWM-6.0NE (1~)
RWD-2.0NWE-200S
RWD-2.0NW(S)E-260S
RWD-2.5NWE-200S
RWD-2.5NW(S)E-260S
RWD-3.0NWE-200S
RWD-3.0NW(S)E-260S
RWD-4.0NWE-260S
RWD-4.0NW(S)E-260S
RWD-5.0NWE-260S
RWD-5.0NW(S)E-260S
RWD-6.0NWE-260S
RWD-6.0NW(S)E-260S
RWH-4.0VNFE
RWH-5.0VNFE
RWH-6.0VNFE
RWH-4.0VNFWE
RWH-5.0VNFWE
RWH-6.0VNFWE
RWH-4.0NFWE
RWH-5.0NFWE
RWH-6.0NFWE
RASM-3VNE
RASM-4VNE
RASM-5VNE
RASM-6VNE
Installation restrictions may be applied
by supply authorities in relation to
harmonics
RAS-8WHNPE
RAS-10WHNPE
- - - -
• Check to ensure that existing installation (main power switches, circuit breakers, wires, connectors and wire terminals) already
complies with the national and local regulations.
• The use of the DHW tank heater is disabled as factory setting. If it is desired to enable the DHW tank heater operation during
normal indoor unit operation, adjust the DSW4 pin 3 of the PCB1 to the ON position and use the adequate protections. Refer to
the section “7.2 Electrical connection” for the detailed information.
