Hitachi ZAXIS 270-3 class User Manual

OPERATING THE MACHINE
5-29
Crusher (ZX120-3 Class)
Maker SANGO JYUKI NPK* Sakato* Oosumi* STK*
Model TS700RCD S-15X SPAC70R-3 MR800 CX750
Weight kg (lb) 1200 (2650) 1410 (3110) 1300 (2870) 1400 (3090) 1250 (2760)
Overall Length mm (ft·in)
1980
(6’6”)
2230
(7’4”)
1620
(5’4”)
1900
(6’3”)
2000
(6’7”)
Rated Pressure
MPa (kgf/cm
2
)
24.5
(250)
20.6
(210)
27.4
(280)
~
31.4
(
~
320)
27.4
(280)
Maximum Opening Width
mm (ft·in)
700
(2’4”)
750
(2’6”)
750
(2’6”)
800
(2’8”)
750
(2’6”)
Swing Method Free Free Free Free
Crusher (ZX200-3 Class)
Maker HITACHI SANGO JYUKI NPK* Sakato* Oosumi* STK*
Model HSC100 HSC160 TS850RCD S-22XA SDS250 RC MR1000L MR1100 DX-900
Weight kg (lb)
2430
(5360)
2300
(5070)
2000
(4410)
2010
(4430)
2390
(5270)
1900
(4190)
2350
(5180)
2100
(4630)
Overall Length mm (ft·in)
2340
(7’8”)
2600
(8’6”)
2400
(7’11”)
2326
(7’8”)
2425
(7’11”)
2200
(7’3”)
2250
(7’5”)
2380
(7’10”)
Rated Pressure
MPa (kgf/cm
2
)
27.9
(285)
27.9
(285)
27.5
(280)
24.5
(250)
31.4
(320)
27.5
(280)
Maximum Opening Width
mm (ft·in)
900
(2’11”)
850
(2’9”)
850
(2’9”)
850
(2’9”)
1050
(3’5”)
1060
(3’6”)
1060
(3’6”)
900
(2’11”)
Swing Method Hydraulic Hydraulic Free Free Free Free Free Free
Jaw Tip Crushing
Force
kN
(tf·f)
640
(65)
980
(100)
970
(99)
834
(85)
Jaw Center Crushing
Force
kN
(tf·f)
980
(100)
1570
(160)
1570
(160)
1470
(150)
1240
(126)
1540
(157)
Crusher (ZX270-3 Class)
Maker HITACHI NPK* Oosumi* STK
Model HSC100 HSC160 S-26X MR1300 CX-1100
Weight kg (lb)
2430
(5360)
2300
(5070)
2520
(5560)
3070
(6770)
2650
(5840)
Overall Length mm (ft·in)
2340
(7’8”)
2600
(8’6”)
2602
(8’6”)
2800
(9’3”)
2450
(8’0”)
Rated Pressure
MPa (kgf/cm
2
)
27.9
(285)
27.9
(285)
24.5
(250)
27.5
(280)
27.5
(280)
Maximum Opening Width
mm (ft·in)
900
(2’11”)
850
(2’9”)
1000
(3’3”)
1300
(4’4”)
1100
(3’7”)
Swing Method Hydraulic Hydraulic Free Free Free
Jaw Tip Crushing
Force
kN
(tf·f)
640
(65)
1080
(110)
Jaw Center Crushing
Force
kN
(tf·f)
980
(100)
1570
(160)
1660
(169)
1540
(157)
Crusher (ZX330-3 Class)
Maker SANGO JYUKI NPK* Sakato* Oosumi* STK*
Model 1100RCD S-35X SDS350 RC MR1500 DX-1500
Weight kg (lb)
2940
(6480)
3500
(7720)
3550
(7830)
4200
(9260)
3400
(7500)
Overall Length mm (ft·in)
2700
(8’8”)
2824
(9’3”)
3285
(10’9”)
2950
(9’7”)
2550
(8’4”)
Rated Pressure
MPa (kgf/cm
2
)
27.5
(280)
27.5
(280)
31.4
(320)
31.4
(320)
Maximum Opening Width
mm (ft·in)
1500
(4’11”)
1100
(3’7”)
1300
(4’3”)
1500
(5’0”)
1300
(4’3”)
Swing Method Free Free Free Free Free
Jaw Tip Crushing
Force
kN
(tf·f)
1180
(120)
1230
(125)
981
(100)
Jaw Center Crushing
Force
kN
(tf·f)
1780
(180)
1770
(180)
2080
(211)
