OPTIONAL ATTACHMENTS AND DEVICES
13-33
SHOE TYPES AND APPLICATIONS
ZX210-3 2-piece Boom
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
900 mm (35”)
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
(lb)
20900
(46100)
21300
(47000)
21600
(47600)
22200
(48900)
Base Machine Weight kg
(lb)
15900
(35100)
16300
(35900)
16600
(36600)
17000
(37500)
Cab Height mm
(ft•in)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
Minimum Ground mm
Clearance (ft•in)
✹
450
(18”)
✹
450
(18”)
✹
450
(18”)
✹
450
(18”)
Undercarriage mm
Length (ft•in)
4170
(13’8”)
4170
(13’8”)
4170
(13’8”)
4170
(13’8”)
Undercarriage Width mm
(ft•in)
2800
(9’2”)
2900
(9’6”)
3000
(9’10”)
3100
(10’2”)
Ground Pressure
47 kPa
(0.48 kgf/cm
2
,
6.8 psi)
41 kPa
(0.42 kgf/cm
2
,
6.0 psi)
36 kPa
(0.37 kgf/cm
2
,
5.3 psi)
32 kPa
(0.33 kgf/cm
2
,
4.7 psi)
ZX210LC-3 2-piece Boom
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
900 mm (35”)
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
(lb)
21500
(47400)
21900
(48300)
22100
(48700)
22600
(49800)
Base Machine Weight kg
(lb)
16500
(36400)
16900
(37300)
17100
(37700)
17600
(38800)
Cab Height mm
(ft•in)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
2950
(9’8”)
Minimum Ground mm
Clearance (ft•in)
✹
450
(18”)
✹
450
(18”)
✹
450
(18”)
✹
450
(18”)
Undercarriage mm
Length (ft•in)
4460
(14’8”)
4460
(14’8”)
4460
(14’8”)
4460
(14’8”)
Undercarriage Width mm
(ft•in)
2990
(9’14”)
3090
(10’2”)
3190
(10’6”)
3290
(10’10”)
Ground Pressure
44 kPa
(0.45 kgf/cm
2
,
6.4 psi)
39 kPa
(0.40 kgf/cm
2
,
5.7 psi)
34 kPa
(0.35 kgf/cm
2
,
5.0 psi)
31 kPa
(0.32 kgf/cm
2
,
4.6 psi)
NOTE: • The specifications for the front-end attachment is for 2.91 m (9 ft 7 in) arm with PCSA 0.8 m
3
(1.05 yd
3
) bucket.
• 700, 800 mm (28, 31 in) and 900 mm (35 in) grouser shoe should not be used on gravel or rocky ground.
•
✹
The dimensions do not include the height of the shoe lug.
