SPECIFICATIONS
12-18
ZX180LC-3, 180LCN-3 (Machine with 2-Piece Boom)
Category
Item
2.26 m (7 ft 5 in) Arm 2.71 m (8 ft 11 in) Arm
mm ft•in mm ft•in
A: Maximum Digging Reach
8980 29’6” 9350 30’9”
B: Maximum Digging Depth
* 5640 * 18’6” * 6050 * 19’11”
C: Maximum Cutting Height
* 10260 * 33’8” * 10530 * 34’7”
D: Maximum Dumping Height
* 7320 * 24’1” * 7590 * 24’11”
E: Overall Height
3030 9’12” 3030 9’12”
F: Overall Length
8850 29’1” 8840 29’0”
G: Minimum Swing Radius
2280 7’6” 2230 7’4”
NOTE: * The dimensions do not include the height of the shoe lug.
T1T1-01-01-006
C
B
D
E
F
A
G
To Next Page
