B.1 Introduction
The PWS-700T is an intelligent operator panel that provides
the high performance and functionality. PWS-700T is a
miniature industrial control operator Panels for your PLC.
Functionally speaking, the PWS-700T is the most compact
member of the PWS Series PLC Workstations family. The PWS-
700T is equipped with a 4.7" (240Hx128V) liquid crystal
display and touch screen. The IP 65 (NEMA 4) rated front
panel seal and INDUSTRIAL GRADE touch screen make the
product rugged and durable. With the CE mark on the product,
you can count on the PWS-700 as a dependable partner of your
applications. It accesses internal relays and registers of
your P.L.C. through a serial port. You can configure the
700T with ADP3, which is a powerfully Windows program that
supports all its sister products.
This chapter describes how to configure and install your
700T.
B.2 General Specification
Item Description
Display Type Blue mode STN LCD
Display Size 4.7" (diagonal)
Number of Pixels 240(H)x128(V)
Display Adjustment Contrast adjustable by external
keys
Back Light CCFT; Life time is 20,000 hours
under normal temperature and
humidity
Touch Screen
Matrix resistive type: Number of
switches is 15×8；ITO glass backing
panel ；
ver 1 million point
activations ； Hard coat is
resistant to most solvents and
chemicals.
Input Power
24VDC±10%; Under 10W
Flash Memory 640K bytes
RAM 128K bytes
Communication Port
(COM2)
25-pin D Type;
Supports RS232/RS422/RS485
Front Panel Seal IP65 / NEMA 4
Operating Temperature
0~50°C
Storage Temperature
-20~60°C
Ambient Humidity 20-90% RH (non-condensing)
Vibration Endurance 0.5mm displacement, 10-55Hz, 2
hours per X, Y, and Z-axis
