HK Audio D.E.A.CON User Manual

D.E.A.CON Manual 1.0
8 Technical specifications
D.E.A.CON Mid/High
Connectors: 1x XLR line in
1x XLR line through
1x XLR subwoofer output
Line in: XLR female (pin 1= ground; 2= +, 3= -)
Input design: Electronically symmetrical & floating
Input impedance: 20 k Ohm
Sensitivity: +10 dBu (turned up to the max)
Max. input level: +22 dBu
Frequency response +/- 3dB:1) 80 Hz–19 kHz fullrange mode
130 Hz–19 kHz satellite mode
Sensitivity 1W@1m:*) 104 dB
Maximum SPL @1m: *) 130 dB@10% THD
Mid/high power amp: 1x 600 W RMS, Class D
Active protection circuitry: DDO™ controller multiband limiter, subsonic filter
MF speaker: 12"
HF horn/driver: 2"
Directivity: 60° x 40° CD horn
Crossover frequency: 900 Hz, 12 dB/ octave
Speaker stand mounting collar: HK AUDIO
®
DuoTilt™, 36 mm, 7.5°, 15°
Flying points: 4x M10 screw thread for optional flying mount
Accessories: D.E.A.CON tilt-unit, 7.5°, 15°
Dimensions (WxHxD): 40 cm x 66 cm x 50 cm / 15-3/4" x 26" x 19-3/4"
Weight: 39.7 kg/ 87.3 lbs.
D.E.A.CON Sub A
Connectors: 1x XLR subwoofer input, 1x XLR subwoofer through
1x Speakon
®
parallel out
Subwoofer input: XLR female (pin 1= ground; 2= +, 3= -)
Input design: Electronically symmetrical & floating
Input impedance: 20 k Ohm
Sensitivity: +10 dBu (turned up to the max)
Max. input level: +22 dBu
Frequency response +/- 3dB: 1) 44 Hz- 130 Hz
Sensitivity 1W@1m: *) 102 dB
Maximum SPL @1m: *) 134 dB
Subwoofer amp: 1x 1000 W RMS, Class D
Active protection circuitry: DDO™ controller, multiband limiter, subsonic filter
Bass speaker: 18"
Speaker stand mounting collar: M20 thread plate
Casters: 4x 80 mm casters on the reverse
Dimensions (WxHxD): 52 cm x 72.5 cm x 71.5 cm / 20-1/2" x 28-1/2" x 28-1/8"
Weight: 49.5 kg/ 109 lbs.
Deacon BDA 1.1 05.10.2004 17:24 Uhr Seite 12
