HK Audio L.U.C.A.S MAX User Manual

TITEL:
ERSTELLT VON:
BLATT:
AM:
ZEICHNUNGS-NR.:
66606 St. Wendel / Germany
VERSION:
REVISION:
GEPRÜFT/
FREIGEGEBEN VON:
AM:
WERKSTOFF:
OBERFLÄCHE:
DATEINAME:
BLÄTTER
INDEX
ÄNDERUNG
ZEICHNER
HK1105-EX-R05-1A-SUB-COMPLETE
HK1105-LUCAS MAX SUB
EXPLOSION DRAWING COMPLETE
HK1105-EX-R04-1A
C. LORIS 2
2
19.04.2006
A1
OBERFLÄCHE
Pos. Artikel-Nr. 1 description Titel Menge
1 1139 Lucas Max front grille assembly Lucas Max Frontgitterbaugruppe 1
2 400273 cabinet Lucas Max subwoofer 40 Holzgeh. Lucas Max Bass 1
3 502188 chassis Lucas Max 220-240V Chassis Lucas Max 220-240V 1
4 970784 Lucas Max protection retainer Blech Lucas Max Schutz-Bügel 1
5 972008 damping wool Dämmwolle Hochbauschvlies 1
6 972047 PE-foam tube PE-Schaumstoff-Röhrchen 8
7 974011 hexagon socket head cap screw, M6x25, black Inbusschraube M6*25 sw 4
8 974013 hexagon socket countersunk head screw, M6x20, black Inbussenkschraube M6x20 sw 4
9 974108 plastic PCB spacer, 6.2x10x15, Polyamid black Dist.Hülse PE 6,2*10*15 [mm] 2
10 974218 ABC-Spax-S chipboard screw, panhead Z, 5x20, black Pan Head-Z ABC-Spax sw 5*20 5
11 974220 hexagon socket countersunk head screw, M6x40, black Inbussenkschraube M6x40 sw 2
12 974233 washer, form A, D=6.4mm, zinc plated Unterleg-Scheibe 6,4 vz 2
13 974322 ABC-Spax-S screws for backwall, 4x20, black Rückwandschraube, 4*20 sw 2
14 974355 cross recessed panhead tapping screw with collar, 3.9x30, black Blechschr. KFR-Kopf 3,9* 30 sw 14
15 974454 plastic PCB spacer, 6.2x10x10, Polyamid black Dist.Hülse PE 6,2*10*10[mm] 4
16 974475 hexagon socket head cap screw, M6x50, black Inbusschraube M6*50 sw 2
17 976001 rubber foot square, self-adhesive, black Gummifuss quadr. selbstkleb. sw 2
18 976009 rubber foot D38*H11 [mm] Gummifuss D38*H11 [mm] 5
19 976015 plug AD=1705 PA, black Lochstopfen AD=1705 PA-schwarz 1
20 976115 connector plate Befestigungsplatte M20 1
21 976159 plastic dish Premium One Griffinnenschale Premium One 2
22* 982037 sealing tape 2x6mm Iso-Zell-Band fadenvers. 2*6mm 0,77 lfdm
23* 982044 sealing tape 2x15mm Iso-Zell-Band fadenvers. 2*15mm 1,32 lfdm
24* 982078 sealing tape 2x20mm Iso-Zell-Band fadenvers. 2*20mm 0,28 lfdm
25* 986016 foam glue, Alfa D 4572 Klebstoff Alfa D 4572 xxx
26* 988011 silicon glue, 310mltrs tube Silicon transparent, 310ml Kartusche xxx
27 994186 B&C 15NW100-4OHMS 4" Coil B&C 15NW100-4OHMS 4" Coil 1
