HK Audio LINEAR 3 Series User Manual

LINEAR 3 1.2
7
6 Technical Specifi cations
Model L3 112 FA L3 112 XA L3 115 FA
Max. SPL peak @ 10% THD 135 dB half space 135 dB half space 135 dB half space
Frequency response +/- 3 dB 65 Hz – 18 kHz 67 Hz – 18 kHz 58 Hz – 16 kHz
Frequency response -10 dB 58 Hz – 18 kHz 62 Hz – 18 kHz 49 Hz – 18 kHz
Output power 1200 watts 1200 watts 1200 watts
Preamp DSP (time alignment) DSP (time alignment) DSP (time alignment)
Amp type Class D - biamped Class D - biamped Class D - biamped
Active protective circuits Under-voltage, thermal, short circuit,
over-current protection, subsonic
filter, look ahead temperature control,
peak, RMS and multiband limiters
Under-voltage, thermal, short circuit,
over-current protection, subsonic filter,
look ahead temperature control, peak,
RMS and multiband limiters
Under-voltage, thermal, short circuit,
over-current protection, subsonic
filter, look ahead temperature control,
peak, RMS and multiband limiters
Low/Mid speaker 1x 12" 1x 12" 1x 15"
HF driver 1" 1" 1"
Horn directivity 90° x 55° CD horn 90° x 55° CD horn 90° x 55° CD horn
Active x-over frequency 2.3 kHz FIR X-Over with 72 dB/oct. 2.3 kHz FIR X-Over with 72 dB/oct. 2.3 kHz FIR X-Over with 72 dB/oct.
Audio ports 2x XLR Combo In bal., 1x Stereo RCA
In, 2 x XLR Thru bal., 1x XLR Mix Out
2x XLR Combo In bal., 1x Stereo RCA In,
2x XLR Thru bal., 1x XLR Mix Out
2x XLR Combo In bal., 1x Stereo RCA
In, 2 x XLR Thru bal., 1x XLR Mix Out
Input sensitivity +4 dBu @ Gain center-notched +4 dBu @ Gain center-notched +4 dBu @ Gain center-notched
Filter presets 2 EQ switches: Bass Boost/Flat
& Flat/Contour
2 EQ switches: Bass Boost/Flat
& Flat/Contour
2 EQ switches: Bass Boost/Flat &
Flat/Contour
Sensitivity switch Line/Mic Input A Line/Mic Input A Line/Mic Input A
Mains connector 1x IEC socket with V-Lock cord retainer 1x IEC socket with V-Lock cord retainer 1x IEC socket with V-Lock cord retainer
Power consumption 3 A / 220-240 V (6 A / 100-120V)
nominal according to EN 60065
3 A / 220-240 V (6 A / 100-120V)
nominal according to EN 60065
3 A / 220-240 V (6 A / 100-120V)
nominal according to EN 60065
Pole mount HK Audio DuoTilt 3/7 HK Audio DuoTilt 3/7 HK Audio DuoTilt 3/7
Suspension points 4x M8 4x M8 4x M8
Grips 2x HK Audio MultiGrip 1x HK Audio MultiGrip,
1x recessed top handle
2x HK Audio MultiGrip
Housing 16 mm MDF 16 mm MDF 16 mm MDF
Front grille 2 mm metal grille backed with black
acoustic foam
2 mm metal grille backed with black
acoustic foam
2 mm metal grille backed with black
acoustic foam
Finish Black acrylic enamel Black acrylic enamel Black acrylic enamel
Optional accessories Cover, Satellite Add-On M20 XLR,
Speaker Stand Add-On Package,
mounting pole M20, Tilt bracket (TB-
N, TB-NQ), Attachment point (AP-8),
Tilt-Unit
Cover, Satellite Add-On M20 XLR,
Speaker Stand Add-On Package,
mounting pole M20, Attachment point
(AP-8), Tilt-Unit
Cover, Satellite Add-On M20 XLR,
Speaker Stand Add-On Package,
mounting pole M20, Tilt bracket (TB-
N, TB-NQ), Attachment point (AP-8),
Tilt-Unit
Dimensions (WxHxD) 36 x 66 x 36,7 cm
14-11/64 x 26 x 14-31/64"
39.5 x 66 x 34 cm
15-9/16 x 26 x 13-25/64"
44 x 69 x 44,5 cm
17-21/64 x 27-11/64 x 17-33/64"
Weight 21.5 kg / 47.4 lbs. 20.6 kg / 45.4 lbs. 27.9 kg / 61.5 lbs.
