HK Audio Linear 5 User Manual

Linear 5 1.0
9
Model L5 112 XA L5 112 FA L5 115 FA L Sub 1200 A L Sub 2000 A
Frequency response
+/– 3 dB
100 Hz – 18 kHz 64 Hz – 18 kHz 57 Hz – 18 kHz 55 Hz – X-Over 49 Hz – X-Over
Frequency response
–10 dB
72 Hz – 20 kHz 57 Hz – 20 kHz 48 Hz – 20 kHz 38 Hz – X-Over 39 Hz – X-Over
Axial sensitivity HF, 1W/1m 110 dB full-space ,
116 dB half-space
110 dB full-space,
116 dB half-space
110 dB full-space,
116 dB half-space
––
Axial sensitivity LF, 1W/1m 98 dB full-space,
104 dB half-space
98 dB full-space,
104 dB half-space
100 dB full-space,
106 dB half-space
95 dB full-space,
101 dB half-space
98 dB full-space,
104 dB half-space
Max. SPL@10% THD 129 dB half-space 127dB half-space 129 dB half-space 126 dB half-space 132 dB half-space
Max. SPL Peak@10% THD 135 dB half-space 134 dB half-space 139 dB half-space 128 dB half-space 133 dB half-space
Max. SPL Calc. 138 dB half-space 138 dB half-space 139 dB half-space 129 dB half-space 135 dB half-space
Amp/type Class D bi-amped Class D bi-amped Class D bi-amped Class D Class D
Power output 1,000 W 1,000 W 1,000 W 1,200 W 1,200 W
Amp to driver 350 W @ 4 Ohms 350 W @ 4 Ohms 350 W @ 4 Ohms – –
Amp to woofer 650 W @ 4 Ohms 650 W @ 4 Ohms 650 W @ 4 Ohms 1,200 W @ 4 Ohms 1,200 W @ 4 Ohms
Protective circuits, amp Under-voltage, thermal, short
circuit, and over-current
protection
Under-voltage, thermal, short
circuit, and over-current
protection
Under-voltage, thermal, short
circuit, and over-current
protection
Under-voltage, thermal, short
circuit, and over-current
protection
Under-voltage, thermal, short
circuit, and over-current
protection
Protective circuits,
speakers
Subsonic 24 dB/oct. peak limiter Subsonic 24 dB/oct. peak
limiter
Subsonic 24 dB/oct. peak
limiter
Subsonic 24 dB/oct. peak limiter Subsonic 24 dB/oct. peak limiter
Power consumption 3 A/230 V nominal pursuant to
EN600056
3 A/230 V nominal pursuant to
EN600056
3 A/230 V nominal pursuant to
EN600056
3.3 A/230 V nominal pursuant to
EN600056
3.3 A/230 V nominal pursuant to
EN600056
Input sensitivity +4 dBu @ Gain center-notched/
L5 System Level
+4 dBu @ Gain center-
notched/ L5 System Level
+4 dBu @ Gain center-notched/
L5 System Level
+4 dBu @ Gain Center click +4 dBu @ Gain center-notched
Audio ports 2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
2x XLR In, 2x XLR-Thru, 2x XLR
Mid/High Out, Speakon NL4 for
2nd passive L Sub 1200
2x XLR In, 2x XLR-Thru,
2x XLR-Mid/High Out
Mains connector 1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock
cord retainer
1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
Bass woofer 1x 12" with 2.5" voice coil
(4 Ohms)
1x 12" with 2.5" voice coil
(4 Ohms)
1x 15" with 3" voice coil
(4 Ohms)
2x 10" (4 Ohms) with 2.5" voice
coil featuring Advanced Cooling
technology
2x 12" (8 Ohms) with 2.5" voice
coil featuring Advanced Cooling-
technology
HF driver 1" with 1.75" voice coil
(16 Ohms)
1" with 1.75" voice coil
(16 Ohms)
1" with 1.75" voice coil
(16 Ohms)
––
Horn directivity 60° x 40° CD horn, rotatable 60°–90° (asy.) x 55° CD horn,
rotatable
60°–90° (asy.) x 55° CD horn,
rotatable
––
X-over frequency 1.65 kHz, 24 dB/oct. active 1.65 kHz, 24 dB/oct. active 1.65 kHz, 24 dB/oct. active 110/130 Hz variable with
24 dB/oct.
100/120 Hz variable with
24 dB/oct.
Pole mount DuoTilt™ 3/7 DuoTilt™ 3/7 DuoTilt™ 3/7 2x M20 M20
Rigging/ pick points 3x M8 3x M8 3x M8 - -
Grips 2, integrated 2, integrated 2, integrated 4, integrated 4, integrated
Optional accessories Protective cover Protective cover Protective cover Protective cover, mounting
hardware for casters, tilt unit
Protective cover, mounting
hardware for casters, tilt unit
Housing Hybrid (birch multiplex / MDF) Hybrid (birch multiplex / MDF) Hybrid (birch multiplex / MDF) Birch multiplex 15/18 mm,
9/13 ply
Birch multiplex 15/18 mm, 9/13
ply
Front grille 2 mm metal grille backed with
black acoustic foam
2 mm metal grille backed with
black acoustic foam
2 mm metal grille backed with
black acoustic foam
2 mm metal grille 2 mm metal grille
Finish Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black
Dimensions (WxHxD) 37 x 66.8 x 30 cm 37 x 66.8 x 36.5 cm 44.9 x 70.8 x 45 cm 38 x 66.8 x 56 cm 50.6 x 80.6 x 61 cm
 14-9/16 x 26-19/64 x 11-13/16" 14-9/16 x 26-19/64 x 14-3/8" 17-43/64 x 27-7/8 x 17-23/32" 14-31/32 x 26-19/64 x 22-3/64" 19-11/16 x 31-47/64 x 24-1/64"
Weight 21.1 kg / 46.5 lbs. 23.9 kg / 52.7 lbs. 30.7 kg / 67.7 lbs. 30.7 kg / 67.7 lbs. 46.2 kg / 101.9 lbs.
Technical Specifi cations
• English • Deutsch • Français • Italiano • Español

HK Audio Linear 5 Specifications

General

Amplifier	Class D
Woofer Size	12"
Inputs	XLR
Output Connectors	XLR
Pole mount	Yes
Handles	Integrated
Finish	Black
Optional accessories	Cover
Dimensions	370 x 570 x 340 mm
