HMD Crest Max - Page 4

• Use the tweezer to lift the ngerprint reader out of back cover
• Remove the ngerprint reader
• Now you can remove the back cover from the device
Step 6: Remove Screws
• Using the screwdriver remove the 8 pcs visible screws
• After removing the 3 boom screws remove the metal plate by lifting its right
edge
• Remove the vulnerable label and remove the screw from below
Step 7: Lift The Motherboard Cover
• Insert the opening tool under the right edge of the motherboard cover and
carefully lift it
• Lift the motherboard cover
• Put the motherboard cover to the side
Step 8: Fold The Black Foil
