Internal
Step 11 — Remove the loudspeaker
Use a T3 Torx screwdriver to remove the seven screws securing the loudspeaker: Four
3.9 mm‑long screws
Three 4.9 mm‑long screws
Insert the tip of a spudger under the center of the loudspeaker's top edge and lift
to release its clips.
Don't pry against the battery and be very careful not to puncture it with your tool.
