Slide an arm of a pair of angled tweezers under the metal neck of one of the
antenna connectors on the charging board and lift straight up to disconnect it. (
Refer Snap-5 ) on next Page.
Make sure the tweezer arm is as close to the head of the connector as possible.
Repeat the process to disconnect the other coaxial connector.
During reassembly:
Use the markings on the board to make sure the cables get connected to the correct
socket—
B for black and W for white. ( Refer Snap -6 on next Page ).
Hold the metal neck of the antenna connector with a pair of tweezers and align
the head over its socket on the board.
Use the flat end of a spudger to press straight down on the connector head—it
should snap into place. If you're having trouble, reposition the head and try
again. Don't try to force the connector into place, or you risk damaging the
charging board.
