13
SADDLE ADJUSTMENT
Loosen seat post screw. Set height according to growth. Tighten up screw. Do not take out seat post
from the main frame.
BREAKING
Stop to pedal when you want stop the item. Magnetic bike M0701 not acquire breaking system or
emergency break.
PARTS LIST
No.
Description
QTY
No.
Description
QTY
1
Computer
1
46
Carriage screw M8*20
2
2
Computer fixed screw M5*12
4
47
M8(subtense13)nylon nut
2
3
Handle bar tube end cap
2
48
Back stabilizer end cap(left)
1
4
Handle bar tube
1
49
Rear stabilizer piece
1
5
Handle bar foam1
2
50
Rear stabilizer washer
1
6
Hand pulse
2
51
M4*12 screw
16
7
Handle bar foam
2
52
Seat
1
8
Hand pulse screw
6
53
Seat tube set
1
9
Hand pulse wire
1
54
Seat support set
1
10
Handle bar cover(back)
1
55
Seat adjustable knob
1
11
Screw M4*20
16
56
Right outer cover
1
12
Screw M5*16
2
57
Belt gap bearing
1
13
Protect wire cap
2
58
M6 nylon nut
4
14
Computer post set
1
59
M6 spring washer
4
15
Screw M8*20
4
60
Flat washer OD16*ID6.5*1.5T
4
16
M8 spring washer
7
61
Belt plate
1
17
Arc washer OD20*ID8.5*1.5T
4
62
Crank leg axes
1
18
Flat washer OD20*ID8.5*1.5T
6
63
Screw M6*18
4
19
Screw M8*72
2
64
Right crank leg
1
20
Front moving wheel
2
65
Right pedal
1
21
Front stabilizer
1
66
Right pedal belt
1
22
Screw M3*12
2
67
Flat washer OD14*ID10.5*1.5T
1
23
Left outer cover
1
68
Adjust wheel
1
24
Crank cover
2
69
Adjust wheel gap bushing
1
25
Left crank cover
1
70
M10 (subtense14)nylon nut
1
26
Screw 5/16-18UNC25
2
71
Spring
1
27
Crank leg cover
2
72
Screw M10*22
1
28
Left pedal
1
73
Adjustable wheel fixed piece
1
29
Left pedal belt
1
74
Gap washer
1
30
Sensor wire upper section
1
75
Fly wheel axes C type buckle %C12
1
31
Handle bar cover(front)
1
76
Fly wheel axes
1
32
Flat washer OD12*ID8*1.5T
1
77
Bearing 6901
1
33
Handle bar knob bushing
1
78
Small belt wheel
1
34
Handle bar knob
1
79
One way axes bushing
1
35
M4*12 screw
4
80
Copper bearing
1
36
Motor
1
81
Bearing 6904
1
37
Belt 370J6
1
82
One way bearing
1
38
Computer post bushing
1
83
Fly wheel
1
39
Pull bolt
1
84
Bearing 6001
1
40
Main frame
1
85
Inner magnetic set
1
41
Sensor wire bellow section
1
86
Seat tube bushing
1
