6.0 TABLE 1 TECHNICAL INFORMATION
Description Units 4822
Motor power kW (hp) .93 (1.25)
Maximum speed of rotating part (50Hz) rpm 1425
Nominal electrical supply Volts/Hz
/ph
230/50/1
Full load current at above voltage Amps 7.4
Locked rotor current at above voltage Amps 41.8
Recommended fuse size amps 10
Minimum ambient temperature
o
C 0
Maximum ambient temperature
o
C 40
Attachment hub drive size -- # 22
Chopper weight (body only) Kg (Lbs) 39 (86)
Chopper with chopping end weight Kg (Lbs) 51 (112)
Noise level dB (A)
##
less than
70
Shipping weight (body only) kg (Lbs) 48 (105)
Chopping end, shipping weight Kg (Lbs) 12 (27)
Shipping dimensions (carton with body only) LxWxH
cm
65.5 x
40.5 x
58.5
Storage conditions. Temperature and humidity.
o
C,
% RH
+5 to +38,
85
Class of appliance -- Class 1
Enclosure IP rating -- IP35
.
##
In accordance with EN-ISO 12001:1996.
7.0
INSTALLATION
7.1
UN-PACKING
Whenever possible the chopper should be transported to the installation position
in the packaging provided to avoid damage. Do not use a sharp knife to cut into
the box as damage to the machine may occur. Check for possible shipping
damage. If the unit is found to be damaged, save the packaging material and
contact your nearest Hobart sales office. Before installing, verify that the
