Hobart 90 C 20 - User Manual

Questions and Answers

J
Jenna MirandaAug 18, 2025
What to do if my Hobart 90 C 20 Inverter engine will not start and the starter will NOT crank the engine?
- L
  Lisa LaraAug 18, 2025
  First, check all battery terminals to ensure they are properly connected. Verify that 13.5 volts DC is reaching the solenoid input terminal. If the issue persists, momentarily connect a large jumper between the hot side of the starter solenoid and the starter input terminal. If the starter then attempts to crank the engine, the starter solenoid is likely defective and needs replacement. If the starter still doesn't operate, the starter itself may be defective and should be replaced. Finally, if all starting components are functional but the engine still won't crank, it could indicate an internal seizure.
A
Andrew GalvanAug 20, 2025
What to do if my Hobart 90 C 20 engine will not start but cranking speed is normal?
- L
  Lori ChaneyAug 20, 2025
  If your Hobart Inverter engine won't start but the cranking speed is normal, the issue might be fuel-related. Start by priming the fuel filters by removing the pipe plug in the cover of each filter and filling them with fuel oil. If the engine still doesn't start, it could indicate a mechanical pump issue. If it starts and then stops, check for problems between the fuel source and the suction side of the pump. Also, ensure there's enough fuel in the tank and the fuel shut-off valve is open. Check for loose connections or damaged hoses, and inspect the fuel filter for clogs or defects. A faulty installation from the return line, a faulty fuel pump, a relief valve that is not seating, worn pump gears, or defects in the injectors, racks, or linkage could also be the cause.
W
wallskarenAug 23, 2025
What to do if my Hobart 90 C 20 Inverter engine will not start and cranking speed is low?
- C
  Corey Smith IIIAug 23, 2025
  If your Hobart Inverter engine won't start and the cranking speed is low, check all battery terminals to ensure they are properly connected and that 13.5 volts DC is reaching the solenoid input terminal. If the issue persists, momentarily connect a large jumper between the hot side of the starter solenoid and the starter input terminal. If the starter then attempts to crank the engine, the starter solenoid is likely defective and needs replacement. If the starter still doesn't operate, the starter itself may be defective and should be replaced. Also, check all connections and connections. Finally, if all starting components are functional but the engine still won't crank, it could indicate an internal seizure.
A
Alexis HinesAug 26, 2025
Why does my Hobart 90 C 20 Inverter engine run at idle speed, but the engine "ON" indicating light does not glow?
- C
  Caitlyn BoyleAug 26, 2025
  The lamp may be defective or the indicating light body may be poorly grounded.
R
Rebecca CurtisAug 27, 2025
What to do if my Hobart Inverter load contactor will not close when the control switch is held in the ON position?
- P
  pwillisAug 28, 2025
  Check all wiring and connections. Remove and inspect the fuse. Check and replace the control switch, if necessary. Disconnect leads at the load contactor coil terminal; resistance should be approximately 600 ohms. If the coil is defective, replace it.
L
Lauren WebsterAug 30, 2025
Why does my Hobart Inverter engine start and then stop after a few seconds due to automatic shut-down?
- I
  Ivan ParkerAug 30, 2025
  The shut-down circuit may have functioned normally to stop the engine because of low lubricating oil pressure or a defective or incorrectly wired high temperature switch.
G
Gary HamiltonSep 2, 2025
What to do if my Hobart 90 C 20 Inverter engine is hard to start, but cranking speed is normal?
- C
  Catherine BryanSep 2, 2025
  The issue may be due to low ambient temperature or limited fuel. You can also check compression. Other potential causes include sticking or burned exhaust valves, worn or broken compression rings, a leaking cylinder head gasket, or improper valve clearance adjustment.
N
Nicole CarlsonSep 4, 2025
What to do if the Hobart 90 C 20 load contactor opens during power delivery and the overvoltage indicating light is ON?
- A
  Alexander PachecoSep 4, 2025
  The overvoltage condition may have resulted from a sudden drop in the load or tampering with the voltage regulator rheostat, which would be a normal action. Alternatively, the over-under-voltage sensing module may be defective. Use the voltage adjusting rheostat to gradually increase voltage. If the over-undervoltage sensing module (K26) opens the load contactor at less than 134 V AC, it is defective and should be replaced.
D
Denise AdamsSep 7, 2025
What to do if my Hobart 90 C 20 engine will not come "up" to governed speed in GEN mode?
- S
  sabrinacookSep 7, 2025
  First, apply 12-V DC directly to terminal 1 on the governor control box. If the engine comes up to speed, check for a defective operating mode switch. Also, check the governor linkage and throttle shaft for any binding or sticking and repair as needed. The control unit may not be receiving a signal from the magnetic pickup, so disconnect the pickup from the control unit and connect a high impedance AC voltmeter to the pickup output leads. Crank the engine without starting it; the voltage reading should be at least one volt. If the voltage is low or zero, check the pickup adjustment and replace the pickup if necessary. Finally, apply 12-V DC to the two actuator input leads; the actuator lever should move to the full speed position immediately. If it doesn't, replace the actuator.
M
Michelle McknightSep 9, 2025
What to do if the Hobart 90 C 20 load contactor opens during power delivery and the over-frequency indicating light is ON?
- D
  Debra OnealSep 9, 2025
  The electric governor may be improperly adjusted or malfunctioning. Alternatively, the over-under-frequency module may be defective. In this case, replace the over-underfrequency relay, or the complete protective relay tray.
