13-4
Handels- Techn.
De Luxe
Excellent
Prestige
Excelsior
t.z.G. zul. Achse Auauf- Zugholm Radbremse
bezeichnung Bez. [kg] Achslast einrichtung
400 SF 30 A 1100 1100 DB 13 M KFL 12 B One Piece 20-2425/1
400 KB 30 A 1100 1100 DB 13 M KFL 12 B One Piece 20-2425/1
410 SFe 30 G 1200 1200 DB 13 M KFL 12 B One Piece 20-2425/1
440 SF 30 F 1200 1200 DB 13 M KFL 12 B One Piece 20-2425/1
450 UF 30 B 1200 1200 DB 13 M KFL 12 B One Piece 20-2425/1
460 UFe 30 C 1300 1300 DB 13 M KFL 12 B One Piece 20-2425/1
460 LU 30 J 1400 1350 DB 13 M KFL 12 B One Piece 20-2425/1
495 UFe 30 E 1400 1400 DB 15 MV/M KF 20 A One Piece 20-2425/1
495 UL 30 D 1400 1400 DB 15 MV/M KF 20 A One Piece 20-2425/1
495 UK 30 D 1400 1400 DB 15 MV/M KF 20 A One Piece 20-2425/1
500 KMFe 30 K 1400 1400 DB 15 MV/M KF 20 A One Piece 20-2425/1
520 TMF 30 M 1500 1500 DB 15 MV/M KF 20 A One Piece 20-2425/1
495 UFe 24 F 1500 1500 DB 15 MV/M KF 20 A ZHL 15 20-2425/1
540 UL/UF/UK 24 M 1500 1500 DB 15 MV/M KF 20 A ZHL 15 20-2425/1
540 UL/UF 24 M 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
540 UL/UF 24 A 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
540 UFe 24 E 1500 1500 DB 15 MV/M KF 20 A ZHL 15 20-2425/1
540 UFe 24 E 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
540 WLU 24 J 1500 1500 DB 15 MV/M KF 20 A ZHL 15 20-2425/1
540 WLU 24 J 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
540 UFf 24 K 1500 1500 DB 15 MV/M KF 20 A ZHL 15 20-2425/1
560 UL/UF 24 B 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
560 UKF 24 B 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
560 KMFe 24 C 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
560 UFf 24 D 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
560 UFe 24 G 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
560 WLU 24 H 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
570 SMF 24 N 1600 1600 DB 16 MV KF 20 A ZHL 15 20-2425/1
610 UL/UF 27 A 1800 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
610 UL/UF 27 H 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
650 UMFe/KMFe 27 B 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
650 KFU 27 C 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
640 SMF 27 F 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
650 UFf 27 J 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
650 WFU 27 G 1900 1000/1000 DB 10 L KF 20 A ZHL 20 20-2425/1
690 SMF 19 H 2000 1050/1050 DB 13 M KF 20 A ZHF 20 20-2425/1
720 UML/UMF 19 D 2000 1050/1050 DB 13 M KF 20 A ZHF 20 20-2425/1
720 UKFe 19 G 2000 1050/1050 DB 13 M KF 20 A ZHF 20 20-2425/1
750 UML/UMF 19 E (•) 2200 1200/1200 DB 13 M KF 25 A ZHL 27 C1 20-2425/1
13.4 Technical data
* The size of the tires that were actually mounted may deviate somewhat from this information.
Trade name
Techni-
cal desi-
gnation
g.v.w.r.
permit-
ted axle
load
Axle
Leading
equipment
Towbar Wheel
brake
