6. Interior structure
53
2
1
Fold-away basin
Mechanism for
fold-away wash basin
'ONTOUR' fold-away basin (model-specic)
Tomakeiteasiertousethetoilet,thewashbasincanbefoldedup.
To fold the wash basin up
• Usethehandle
j
toguidethewashbasinupwards.Thelock
k
gripsunderthewashbasin.
To fold the wash basin down
• Pullagainonthehandle
j
.Thelock
k
willautomatically
givewaytoslightresistance.
Iftheclipsdonotautomaticallylockandunlock,they
mustbemovedmanually.
6.5 Washroom
1
2
Securing the shower door while driving
Closed shower door
Shower cubicle door in the rear washroom
To fold the shower door out
• Loosenthepushbutton
j
.
• Foldoutthehandles
k
ontheshowerpartition.
• Foldouttheshowerdoorandguideittotheoppositeside.
To shut the shower door
• Guidetheshowerdoorbacktoitsoriginalpositionandfolditup.
• Pushthehandles
k
backinuntiltheylieatagainsttheshower
partition.
• Lockthepushbutton
j
.
Theshowerdoorintherearwashroommustbesecu-
relyfastenedwhendriving.

Hobby ONTOUR 2018 Specifications

General

Berths	4
Maximum permissible mass	3500 kg
Power	130 hp
Transmission	6-speed manual
Seats	4
Fuel Type	Diesel
Overall width	2330 mm
Engine	2.3 Multijet
Water Tank	100 liters
Waste Water Tank	96 liters
Fuel Tank	90 l
