LOAD DATA PROGRAM
This program calls back the data that was stored at “Save Data” program.
To load the data, press Start/Enter key once to blink the data number field
and select the number using INC or DEC key then press Start/Enter key for
more than 3 seconds.
Select the data number to be called back.
The data matched with the number will be displayed at this time.
Loading the data.
VARIOUS INFORMATION DURING THE PROCESS
You can inquire various information on LCD screen during charging or discharging process. When you press DEC
button the charger shows the establishment of user settings. And also you can monitor the voltage of individual
cell by pressing INC button when the individual connection cable is linked to the Lithium battery being processed.
The final voltage will be reached at the end of process.
Capacity Cut-Off
ON 5000mAh
Safety Timer
ON 200min
The 3-pin port is assigned as an USB port.
The external temperature only will be displayed when using the thermal
probe.
The present voltage of input power.
Using the individual connection cable to the battery, you can check the
individual voltages of each cell in the battery pack. When connect the cable
to the port on the right side of the charger the program shows the voltage
of each cells for maximum 6 cells in sequence. To utilize this feature, the
battery pack must have output connector that linked to each cells.
PROGRAM SELECT
LOAD DATA
LOAD [01] NiMH
14.4V 3000mAh
Load...
End Voltage
12.6(3S)
USB/Temp Select
USB Enabled
Ext.Temp 26C
IN Power Voltage
12.56V
4.14 4.16 4.09
0.00 0.00 0.00
To Next Page
Loading...
