INSTALLATION INSTRUCTIONS
1. Inspect thermoelectric cooler. Verify functionality before mounting the thermoelectric cooler, see
HANDLING & TESTING THE THERMOELECTRIC COOLER on page 3.
2. Using the cutout dimensions shown in this manual, prepare the air openings, and mounting bolt hole
pattern for the enclosure.
3. Mount thermoelectric cooler on enclosure using mounting fasteners provided.
4. Refer to top of nameplate for electrical requirements. Connect the thermoelectric cooler to a properly
grounded power supply.
Design Data
Model Description Voltage
Full Load
Amps
Nominal
Cooling/
Heating
Watts
Maximum
Ambient
Temperature
°F / °C
Shipping
Weight
lb. / kg
TE090624020 60 Watt 24 Volt TEC No Shroud 18 - 27.6 Vdc 4.4 @ 27.6 Vdc 52 / 64 131 / 55 7.5 / 3.4
TE121024020 100 Watt 24 Volt TEC No Shroud 18 - 27.6 Vdc 8.5 @ 27.6 Vdc 94 / 94 131 / 55 10.8 / 4.9
TE121048020 100 Watt 48 Volt TEC No Shroud 40 - 56.7 Vdc 4.4 @ 56.7 Vdc 94 / 94 131 / 55 10.8 / 4.9
TE162024020 200 Watt 24 Volt TEC No Shroud 18 - 27.6 Vdc 14.7 @ 27.6 Vdc 166 / 144 131 / 55 16.9 / 7.7
TE162048020 200 Watt 48 Volt TEC No Shroud 40 - 56.7 Vdc 7.6 @ 56.7 Vdc 166 / 149 131 / 55 16.9 / 7.7
TE090624010 60 Watt 24 Volt TEC Galvanized Shroud 18 - 27.6 Vdc 4.4 @ 27.6 Vdc 52 / 64 131 / 55 9.3 / 4.3
TE121024010 100 Watt 24 Volt TEC Galvanized Shroud 18 - 27.6 Vdc 8.5 @ 27.6 Vdc 94 / 94 131 / 55 13.3 / 6.1
TE121048010 100 Watt 48 Volt TEC Galvanized Shroud 40 - 56.7 Vdc 4.4 @ 56.7 Vdc 94 / 94 131 / 55 13.3 / 6.1
TE162024010 200 Watt 24 Volt TEC Galvanized Shroud 18 - 27.6 Vdc 14.7 @ 27.6 Vdc 166 / 144 131 / 55 20.7 / 9.4
TE162048010 200 Watt 48 Volt TEC Galvanized Shroud 40 - 56.7 Vdc 7.6 @ 56.7 Vdc 166 / 149 131 / 55 20.7 / 9.4
TE090624011 60 Watt 24 V TEC Stainless Steel Shroud 18 - 27.6 Vdc 4.4 @ 27.6 Vdc 52 / 64 131 / 55 9.3 / 4.3
TE121024011 100 Watt 24 V TEC Stainless Steel Shroud 18 - 27.6 Vdc 8.5 @ 27.6 Vdc 94 / 94 131 / 55 13.3 / 6.1
TE162024011 200 Watt 24 V TEC Stainless Steel Shroud 18 - 27.6 Vdc 14.7 @ 27.6 Vdc 166 / 144 131 / 55 20.7 / 9.4
