PRODUCT DATA
PAIR WITH RF RECEIVER
OUTPUT RF signal
OPERATION FREQUENCY 869.5/916.5/434MHz
POWER SUPPLY 3V(1xCR2032 battery)
OPERATING TEMPERATURE 0-40°C
RELATIVE HUMIDITY 8% to 80%
DIMENSIONS 150x38.6x12mm
• Control 5 zones of receivers separately
• Single color controller
• Compatible with all universal series RF receivers
• Waterproof grade: IP20
• The remote control is suitable for the LED dimmers with
article code SR-1009SAC and SR-1009SAC-HP
Magnetic Bracket
Step 1: Do wiring the RF receiver according to wiring diagram (please refer to the
instruction of RF receiver that you would like to pair with).
Step 2: Click the “Learning Key” button on RF receiver or re-power on the receiver three times
continuously to set it into pairing status
Step 3: Choose one zone and click I or O of the zone(e.g. zone 2), LED lights connected with the
RF receiver icker once means the receiver is paired with zone 2 successfully.
Note: one receiver can be paired with max 8 remote controls.
If you use multiple receivers, you have two choices:
Option 1: have all the receivers in the same zone, like zone 1
Option 2: have all the receivers in different zones, like zone 1, zone 2, zone 3,
zone 4 and zone 5.
By using the different zone buttons, you can easily control the different zones. You can also
choose to switch on one or more zones and switch off the others by the use of the main button.
Learning Key
RF LED Receiver
EN
