Hohem iSteady Pro 4 - Mounting the Action Camera

7
Mounting the Action Camera
Do not turn on the gimbal without an action camera
mounted on.
Pull the quick release clip (spring) and snap it into the groove to secure the camera.
If the power button or charging port is blocked, please adjust the direction of motor axis
after installing the camera as shown above.
Maximum Payload
160g
Compatible Cameras
GoPro Hero 10/9/8/7/6/5/4/3
DJI OSMO Action
Insta360 ONE R (4K & 1-inch)
SONY RX0
other action camera with similar size and weight
Maximum Camera Size
Height: 51m; Depth: 30mm
Cameras that can be
controlled with the handle
GoPro 10/9/8/7/6/5
(GoPro 7 white & silver version is not supported)
