154 Vehicle care
22. Data link connection
23. Discrete logic ignition sensor
24. Outside rear view mirror
25. -
26. -
27. -
28. Instrument panel cluster
29. Air bag ignition
30. -
31. Front window
32. Auxiliary power outlet
33. -
34. Run relay
35. Logic mode relay
36. Accessory/retained accessory
power relay
37. -
38. Radio
39. Heating ventilation and air
conditioning
40. -
41. Spare fuse
42. Spare fuse
43. Spare fuse
44. Spare fuse
45. Spare fuse
46. Spare fuse
Vehicle tools
Tools
Tyre repair kit
The vehicle may have an emergency
tyre sealant and compressor kit in
place of a spare tyre.
The tools, tyre sealant and
compressor kit are located below the
oor cover, in the load compartment.
