Holman QCS2 Series - QCS2;RCS2;Q2;Q2 E Series Parts - Part 2

26
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
3
4
PARTS LIST February 3, 2011, Rev. D
Models: Q2-500-120V, Q2E-500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK, Q2-600HF-208, Q2-600H-208/220/240V,
Q2-600HS-208, Q2E-600H-208/240V, Q2-800-208/220/240V, Q2-800-240UK, Q2-800-230CE, Q2E-800-208/240V,
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2--1200-208/240V, R2-600HJ-208/240V, R2-800-208V
CONVEYOR TOASTERS
Fig
No
Part No. Qty Description Application
20
HA-120239
1
SPEED CONTROL ASSEMBLY Q2-500-120V, Q2-500-CUL20
HB-120259 SPEED CONTROL ASSY 250 Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V
HB-120261 SPEED CONTROL ASSY 500
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-600H-CE, Q2-600H-UK,
R2-600HJ-208/240V, R2-800-208V
21 2P-402728 1 POT, ANTI SPIN PLATE ALL NON-ELECTRONIC
22
2J-200538
2
SWITCH, EGO 240V INFINITE
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V, R2-
12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2-500-120V,
2J-200539 SWITCH, EGO 120V INFINITE Q2-500-120V, Q2-500KL-120, Q2-500-CUL20
23 2E-200551 1 SWITCH ROTARY
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V, R2-
12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2-500-120V,
Q2-500-CUL20
24 2R-200709 4 LEG 1” CHOME PLASTIC
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V, R2-
12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2E-600H-
208V
25
2M-200864
1
LABEL, QCS-2 & 3 CONTROLS
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-500-120V, Q2-500-
CUL20, Q2-600H-CE, Q2-600H-UK
2M-200894 LABEL, QCS-2&3 BAGEL CONT Q2-1200B-208/240V
2M-201810 LABEL, RCS-2&3 BAGEL CONT
R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, R2-800-
208V
2M-201813 LABEL, QCSE Q2E-600H-208V, Q2E-500-120V, Q2E-500CUL20
2M-Z13358 LABEL - CONTROL Q2E-600HW Q2E-600HW
2M-Z13864 LABEL - CONTROL PANEL R2E R2E-500-120V, R2E-800-208V
26
2R-200768 1
KNOB, CNTRL Q SERIES,
SPEED
Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-500-120V, Q2-500-
CUL20, Q2-600H-CE, Q2-600H-UK
2R-200769
3
KNOB, POWERSAVER Q
SERIES
Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208V, Q2-500-
120V, Q2-600H-CE, Q2-600H-UK
1
KNOB, POWERSAVER Q
SERIES
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-
208/240V
27 2R-200708
4 KNOB, CONTROL CAP
Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2-
500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK
2 KNOB, CONTROL CAP R2-12BSZ-208/240V, R2-1200B-208/240V
28
HA-100560
1
TRAY, PULL OUT QCS, 10” ALL
HF-100562 SECURITY TRAY, PULL OUT ALL SECURUITY UNITS
29 2R-200787 1 QCS 1&2 CRUMB TRAY GUARD ALL
30
HC-402457
1
CRUMB TRAY, QCS-2 ALL
HF-100656 SECURITY CRUMB TRAY, QCS Q2-600HS-208
31 2B-200763 1 LOADUP, 10 EURO, WIRE ALL
32 HF-101115 1 TRAY, CRUMB TRAY ASSEMBLY ALL
33 2B-Z10675 2 MASTERLINK 10” CONV ALL
34 SP-160027 1 BELT, CONVEYOR 10” ALL
35 2A-202904 1 SHAFT, 210HX IDLER ALL
