Holman QCS2 Series - Q3-950 H;Q3-1000;Q3-1300 Series Parts - Part 1

28
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
1
3
PARTS LIST January 25, 2011, Rev. D
Models: Q3-950H-208/220/240V/CE/UK, Q3-1000-208/220/240/CE/UK, Q3-1300-208/240V, Q3-1400BH-208/240/CE,
Q3-1600B-208/240, Q3E-950H-208/240, Q3E-1000-208/240, Q3E-1300-208/240
CONVEYOR TOASTERS
Fig No Part No. Qty Description Application
1 HC-120283 1 CHASSIS ENCLOSURE ASSY ALL
2
HC-120284
1
ASSY, AIR BAFFLE QCS-3 LO Q3-950H-208/240
HC-120285 ASSY, AIR BAFFLE QCS-3 HI Q3-1400BH
3 2R-Z8879 1 2-5/8 DIA FAN BLACK CW ALL
4
HA-120243
1
MTR,ASSY,QCS,220,230,240V Q3-950H-CE, Q3-1000-CE, Q3-1000-UK, Q3-1400BH-CE
HB-120262 MOTOR ASSY 208-240V Q3-950H, Q3-1000-208V, Q3-1300-240V, Q3-1400BH208
HC-120289 MOTOR ASSEMBLY QCS3 Q3-1300-208V
HI-115071 MOTOR, RMS72, W/TERMINALS Q3E-1300-208
5 2U-200561 1 MOTOR,FAN240V 23BTM ALL
6 HC-Z11212 1 BACK PANEL,QCS-3 ALL
7 2A-202902 1 SHAFT, T714 DRIVE ALL
8
HA-112261
2
BEARING ASSY, 5/16 TEFLON Q3-950H, Q3-1000
HA-112263 BEARING ASSY PTFE/BRONZE Q3-1300, Q3-1400BH,
9 2P-Z8779 1 SPROCKET 25P-11T .313 ID ALL
10 2P-150013 1 DRIVE CHAIN #25 ROLLER Q3-950H-208/220/240V, Q3-1000-208V
11
2P-200645
1
SPROCKET, 25B17 X 5/16 Q3-950H, Q3-1000, Q3-1400BH
2P-200648 SPROCKET, 25B32 X 5/16 Q3-1600B
12
GB-197847
4
HEATERTUBE, QUARTZ, 240V Q3-950H-240V, Q3-1000-240V, Q3E-950H-240V, Q3E-1000-240V
HL-197862 HEATERTUBE, QCS-3-1600B Q3-1600B-208
HL-197863 HEATERTUBE, QUARTZ Q3-1600B-240
HT-197845 HEATERTUBE, QUARTZ, 208V Q3-950H-208V, Q3-1000-208V, Q3E-1000-208V, Q3E-950H-208V
HT-197846 HEATERTUBE, QUARTZ, 220V
Q3-950H-220V, Q3-950H-CE, Q3-1000-220V, Q3-1000-CE,
Q3-1000-UK
2N-209130 ELEMENT, METAL 208V 800W R3-950H-208V
2N-209160 ELEMENT, METAL 240V 800W R3-950H-CE
GB-197847
6
HEATERTUBE, QUARTZ, 240V Q3-1400BH240
HJ-198054 HEATERTUBE, QCS-3-1300 Q3-1300-240V, Q3E-1300-240V
HJ-198060 HEATERTUBE, QCS-3-1300 Q3-1300-208V, Q3E-1300-208V
HK-198066 HEATERTUBE, QCS-3-1400BH Q3-1400BH-CE
HT-197860 HEATERTUBE, QUARTZ Q3-1400BH-CE
13
HC-Z10390
1
ELEMENT RETAINER,RHT,QCS- Q3-950H, Q3-1000, Q3E-950H, Q3E-1000, Q3E-1300
HC-Z11287 ELEMENT REATINER-RH, RCS-2 R3-950H
HC-Z10440 ELEMENT RETAINER, RIGHT Q3-1400BH, Q3-1600B
14
HB-Z10858
2
ELEMENT GUIDE PLATE QCS2 Q3-950H
HC-Z10388 ELEMENT GUIDE PLATE Q3-1000, Q3-1300, Q3E-1000, Q3E-950H-208
HC-Z10439 ELEMENT GUIDE PLATE 1200 Q3-1400BH, Q3-1600B
15 2E-Z10406 2 TERMINAL BLOCK 4 POS Q3-950H, Q3-1000, Q3-1600B,
16 2E-Z9736
1
TERMINAL BLOCK - POWER
Q3-950H, Q3-1600B,
2 Q3-1000
17 2K-200464
1
BUSHING, WIRE RING 7/8”
Q3-1400BH
2 Q3-950H, Q3-1000
18 2E-200566 1 SWITCH, RESET, 0796 ALL
19 2R-200562 1 FAN GUARD ALL
