Holman QCS2 Series - Q3-950 H;Q3-1000;Q3-1300 Series Parts - Part 3

30
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
3
3
PARTS LIST January 11, 2011, Rev. D
Models: Q3-950H-208/220/240V/CE/UK, Q3-1000-208/220/240/CE/UK, Q3-1300-208/240V, Q3-1400BH-208/240/CE,
Q3-1600B-208/240, Q3E-950H-208/240, Q3E-1000-208/240, Q3E-1300-208/240
CONVEYOR TOASTERS
Fig No Part No. Qty Description Application
NI 2E-Z5681 1 FUSEHOLDER, CLASS G Q3-1300-208V, Q3-1400BH
NI 2E-Z5681 2 FUSEHOLDER, CLASS G Q3E-1300-208/240V
NI 2K-200465 1 BUSHING,CORD HEYCO12/3 BL Q3-950H, Q3-1400BH208
NI 2K-Y2968 1 BUSHING - HEYCO Q3-950H-CE, Q3-1400BH-CE
NI 2P-200267 1 WIRE BRUSH
NI HB-120269 1 CORD ASSY 6-20P W/3 #10R Q3-950H-208/220/240V
NI HB-120272 1 ASSY, CORD SET, 6-30P Q3-1300-208V, Q3-1400BH208, Q3-1600B-208
NI HB-120276 1 CORD ASSEMBLY CEE7-7 Q3-950H-CE, Q3-1000-CE, Q3-1400BH-CE
NI HG-402144 1 FAN SWITCH BRACKET Q3-1600B
