Page 14 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57056
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
J,($#%T"#$%,89%U",3(,5
JT6FE6%K6FU%G[6%;ITTIQLMR%OFK6;PTTH
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
J,($#%T"#$
K*4&(9%J(&9'4$c#%E*(",7%M'5+*(%[*(*-%
M&$*- If product has no serial number, record month and year of purchase instead.
M&$*- Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
J,($ U*#4("/$"&8 i$V
1
Reservoir Tank
1
2 Cover Housing Ring 1
3 Fluid Coupler Retaining Ring 1
4 Cover Housing 1
5 Tank Plug 1
6 Handle Insert 1
7 Handle Cover 1
8 Screw 1/4 x 3/4 1
9 Tank O-Ring 134.4 x 3.1 2
10 38 mm Float Ball 1
11 Tank Base 1
12 Rubber Cap 2
13 Pump Housing Gasket 1
14 Washer 1/2 x 32 1
15 Valve 1/4PT x 1/4PS 1
16
90 Degree Adaptor 1/4PT
1
17 Extracting Tube Fluid Coupler 1
18 O-Ring 27.7 x 3.5 1
19 L Insert Adaptor 8 mm x 45L 1
20 O-Ring 5.5 x 2 2
21 Nylon Hose 6 x 8 x 600 mm 1
22 Insert 8 mm x 1/4PT 1
J,($ U*#4("/$"&8 i$V
23
Converter
1
24 90 Degree Adaptor 1
25 Hose 5.5 x 9 x 82 mm 1
26 Clip 2
27 Venturi 1
28 Insert PS1/8 x Ø6.5 1
29 Plug PT1/8 1
30 Muffler 1
31 Clip 27 mm 1
32 Tube 1/4 x 2.8 x 580L 1
33 Extracting Tube 7.5 x 10 x 1500 mm 1
34 Extracting Tube 5 x 7 x 1500 mm 1
35 Extracting Tube 4 x 6 x 1500 mm 1
36 Valve 1/4PT x 1/4PS 1
37 Valve Handle 1
38
Screw M3 x 10
1
39 Insert 1
40 PVC Hose 6 x 10 x 500 mm 1
41 Insert 1/4 x D4*L45.5 2
42 Bleed Screw Adapter 1
43 Tube Connector 1
44 PVC Hose 6 x 10 x 1500 mm 1
To Next Page
