Holybro Pixhawk 4 S500 V2 Basic Kit - Pixhawk 4 Wiring Connections

Figure 36
Step 11: Pixhawk 4 wiring
The Pixhawk 4, which has several different wires and connections with it. Included below is a
picture of every wire needed with the Pixhawk and how it looks when connected.
Plugin Telemetry and GPS module to the flight controller as seen in Figure 37; plug in the
RC receiver, all 4 ESCs to the flight controller as well as the power module as shown in
Figure 37.
