machines technical requirements like
max. diameter, spindle diameter and es-
pecially check whether the cutter is de-
signed for the spindle rotation speed of
the milling machine.
Always feed the work towards the
cutter in the direction opposite of the
cutter rotation.
Your hands must not come nearer
than 12 inches (~ 30cm) to the cut-
ters. Never reach directly across or over
the cutters. Never reach behind the cutter
to grap the workpiece.
Beware of material kickbacks! The
danger of kickbacks is increased when:
the workpiece has knots, holes or foreign
objects in it. Warped or uneven workpieces
should be planed before shaping or prol-
ing them with the spindle shaper.
Never force a workpiece through the shaper
when feeling resistance - high danger of
kickback! Let the cutters do the work and
reduce the feeding speed.
Keep your cutters evenly sharp. Blunt or
uneven cutters increase kickback prob-
ability dramatically.
Never attempt to remove too much
material in one pass. You will enjoy bet-
ter working results and a higher safety
level if you split the work into multiple
passes.
INTENDED USE
This machine is intended to be used for
straight proling and shaping of wood
with different cutters. The machine is not
designed for shaping along curves.
The workplace must have:
Sufcient lighting conditions to prevent
shadows or eye strain.
Access to a suitable dust collecting sys-
tem!
A clean, level underground that is vibra-
tion resistant!
Enough place around the machine for safe
handling and feeding of the material.
A proper, compatible electric supply cir-
cuit.
Humidity: max. 90% for max. 25°C
max. 70% for max. 40°C
Do not use the machine outdoors.
Do not use the machine in workplaces with
explosion and re hazard.
RESIDUAL RISKS
The work with a spindle moulder always
contains a certain risk that can never be
eliminated entirely. This is a non complete
shortlist indicating some of the most dan-
gerous remaining residual risks:
Risk of personal injury due to workpiece
kickback.
Risk of injury through rotating cutter-
heads.
Risk of electrocution when touching lead-
ing machine components.
You can minimize these residual risks by
following all security, maintenance and
operation rules.
MACHINE MISUSE
Any use that does not comply with the
security rules, workplace requirements,
maintenance guidelines or operation rules
described in this manual.
HOLZMANN Maschinen cannot be made li-
able for any damages to machine and per-
son being a direct or indirect consequence
of inproper use of the machine.
2. MACHINE SPECIFICATION
The FS 160L is a High Quality spindle
moulder for the sophisticated private
user.
MACHINE OVERVIEW
1. Outfeed fence
2. motor compartment door
3. sliding table lock
4. ON/OFF/Emergency OFF Button
5. Spindle rotation lock
6. spindle height adjustment wheel
7. infeed fence
8. fence securing bolt
TECHNICAL DATA
Motor power S1/S6 1.5kW / 2.1kW
supply voltage 230V or 400V
Spindle diameter 30mm
Spindle travel 110
Spindle speeds 1400/4000/
6000/9000 rpm
table opening 170mm
max. tool Ø
below table 144mm
above table 160mm
max. tool height 105mm
dust port Ø 100mm
Table size 600x400mm
