OPERATION
HOLZMANN Maschinen Austria www.holzmann-maschinen.at Seite 18
Kreissägeblattschärfmaschine/ circular saw blade grinder MTY 8-70
13 OPERATION
fixation
an
gle
ad-
jus
tm
ent
Distance between the
bolt and the grinding
wheel = teeth distance
Fence (bolt)
fence allows
removal rate
defined at
Sawtooth.
The inclusion of the saw
blade has to be positioned in
accordance with the blade
diameter of the handwheel.
Plate with pins
can be adjusted
to the correct
distance after
releasing the re-
spective screws
Using the pivot-
ing blade hold-
er, each blade
can be adjusted
easily.
Corundum
disc for CV
saw
blades
available
at
Holzmann
flap
Ability to
move forward
