HOMCOM 370-061 User Manual

PARTS NAME
INSTALLATION
1.AS PICTURE, PUT TWO REAR WHEELS INTO THE TUBE
UNTIL HEAR THE LOCK SOUND .
2.AS PICTURE,TWO SIDES PLASTIC
INSERT THE TWO SIDES OF FRONT
FORK TUBE,FIX WITH SCREW.
1.FRONT WHEEL ASSEMBLY 2.FRONT FIRM SCREW 3.FRONT FORK 4.FENDER 5.MAIN FRAME
6.FRONT BASKET 7.HANDLE FIRM SCREW 8.OVERLAY 9.BELL 10.HANDLE COVER 11.GUARDRAIL
12.CANOPY 13.FOOTREST 14.DIRECTION CONTROL SYSTEM 15.ROTATE SEAT BUTTON
16.PUSH BAR 17.BOTTLE CARRIER 18.BACKREST 19.SEAT FABRIC 20.REAR BASKET SCREW
21.REAR BASKET 22.REAR WHEEL ASSEMBLY
16
13
14
15
11
12
10
8
9
7
6
5
19
18
20
21
17
22
1
4
3
2
EN
