5
Assembly Instruction
Front wheels assembly
A.Wheel
B.Washer
C.Nut
D.Wheel cover
Assembly the left front wheel and fasten with nut by socket tool as picture shown,
same process for the other side.
Rear wheels assembly
A. Main body B. Small cover C. Rear axle
1.Insert the rear axle to main body from left to right as picture shown.
2.Fix the rear axle with nut and screw.
3.Place the small cover to main body as picture shown.
