Parts Identification
Display
Left Pedal
Pedal Arm
Knob
Right Pedal
Front Stabilizer
Rear Stabilizer
Assembly
The trainer is easy to assemble.
Respectively mount the front and rear stabilizers to the main body with two sets of hex bolts.
Next, attach the right and left pedals to the main body.
The right pedal is mark R while the left is marked L.
Screw the right pedal clockwise to the pedal arm and then screw the left pedal anti-
clockwise to the pedal arm. Afterwards, secure the pedals up with a wrench.
Tips for Installing the Pedals
Make sure the pedal is straight when you screw it in.
Rotate the shaft with your fingers to get the threads started. 3. If you can’t get the
threads started with your fingers then it is cross threaded. Unscrew the pedal, make
sure the pedal is straight, and then try again.
