INDEX
Subject Page
1. General safety precautions 3
2. Declaration of incorporation of partly completed machinery 4
2.1 Machinery Directive
4
3. Technical data 5
3.1 Operating instructions
6
3.2 Dimensions
6
4. Standard installation 7
5. Main components 8
6. Assembling belt and chain 9
7. Assembling the automation 10
8. Tensioning belt and chain 11
9. Mechanical installation 12
10. Fastening the arm 13
11. Installation of the end stops 14
12. Installation of the manual release 15
13. Installation of the GLOBEC adapter for up-and-over doors 16
14. Installation of the GLOBESI intermediate support 17
15. Electrical connections 18
16. Commands 19
17. Outputs and accessories 20
18. Settings 21
19. Radio receiver operation 23
20. Start up 24
21. Troubleshooting 25
22. Routine maintenance plan 25
23. Operating instructions 26
23.1 General safety precautions
26
23.2 Manual release instructions
27
CAPTION
i
STOP
This symbol indicates instructions or notes regarding safety issues which require particular attention.
This symbol indicates informations which are useful for correct product function.
This symbol indicates options and parameters which are only available with the indicated item.
This symbol indicates options and parameters which are not available with the indicated item.
This symbol indicates instructions or notes intended for technical and expert personnel.
This symbol indicates operations not to be effected for not compromise the correct operation of the
automation.
All right reserved
$OOGDWDDQGVSHFL¿FDWLRQVKDYHEHHQGUDZQXSDQGFKHFNHGZLWKWKHJUHDWHVWFDUH7KHPDQXIDFWXUHUFDQQRW
KRZHYHUWDNHDQ\UHVSRQVLELOLW\IRUHYHQWXDOHUURUVRPPLVLRQVRULQFRPSOHWHGDWDGXHWRWHFKQLFDORULOOXVWUDWLYH
purposes.
