UK - Page 15
STOP
Fig. 14
CHOKE LEVER
Fig. 15
THROTTLE TRIGGER
TRIGGER
RELEASE
Fig. 16
Fig. 18
RUN POSITION
STARTER
GRIP
STARTING A COLD ENGINE:
3. Move the chain brake to the BRAKE position.
NOTE: Set the chain brake by pushing the chain brake
lever/hand guard forward (towards the bar) to the brake
position. Refer to “Operation – Operating Chain Brake”
for additional information.
4. Set the ignition switch to the RUN (I) position.
5. Fully press and release the PRIMER BULB 7 times.
6. Pull CHOKE lever all the way OUT to full position. The
partial throttle position is automatically set when the
choke lever is set at full choke.
OPERATION
Fig. 17
STARTER
GRIP
CHOKE
LEVER
