3
HOMELITE PRESSURE WASHER — MODEL NO. HL252300
FIGURE A PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
The model number will be found on a label attached to the frame. Always mention the model number in all correspondence regarding your PRESSURE
WASHER or when ordering replacement parts.
1 309591066 Engine ............................................. 1
2 678041002 Output Shaft Key (3/16 x 35 mm) ... 1
3 308418004 Pump ............................................... 1
4 308582026 Main Frame ..................................... 1
5 518790009 Nozzle Holder .................................. 1
6 561307003 Rubber Foot .................................... 1
7 308638023 Handle Assembly (Inc. Key No. 8) ... 1
8 308421004 Lock Button w/Spring Clip .............. 2
9 308316002 Wand Holder (Upper) ...................... 1
10 678016006 Lock Nut (1/4-20) ........................... 6
11 661557011 Bolt (5/16-24 x 27 mm, Hex Hd.) .... 4
12 638678001 Lock Washer (5/16 in.) .................... 4
13 638675002 Washer (5/16 in.) ............................. 4
14 661501007 Screw (1/4-20 x 2.0 in., Torx) .......... 4
15 678169004 Thermal Release Valve .................... 1
16 661503004 Bolt (1/4-20 x 1-1/4 in.) ................... 1
17 638128004 Washer (1/4 in.) ............................... 1
18 660764002 Bolt (M8 x 40 mm,
Hex Flange Hd.) .............................. 4
19 308835006 Hose ................................................ 1
20 310801001 Hook and Loop Strap...................... 1
21 308760019 Trigger Handle ................................. 1
22 308506006 Extension Wand .............................. 1
23 308451018 Wheel Assembly (10 in. x 3 in.) ....... 2
24 308697013 Nozzle, 0º ........................................ 1
25 308700013 Nozzle 40º ....................................... 1
26 308699013 Nozzle 25º ....................................... 1
27 308706006 Soap Nozzle .................................... 1
28 620599014 Axle ................................................. 2
29 678238001 Hitch Pin .......................................... 2
30 638275002 Washer (1/2 in.) ............................... 2
31 678243008 Wand Holder (Lower) ...................... 1
32 661505003 Bolt (M8 x 50 mm, Flange Hd.) ....... 1
33 678774001 Lock Nut (M8 x 1.25) ....................... 5
34 518391001 Filter ................................................ 1
35 561399003 Chemical Siphon Tube .................... 1
36 940617071 Pump Start Label ............................ 1
37 940617072 Engine Start Label ........................... 1
38 940633005 Recoil Label .................................... 1
39 940647049 Choke Label .................................... 1
40 940678136 Data Label ....................................... 1
41 940680027 Hot Surface Label ........................... 1
42 940705095 Trigger Handle Logo Label .............. 1
43 940748005 Homelite Label ................................ 1
44 940779038 Performance Label .......................... 1
45 940871002 Add Oil Label .................................. 1
46 940894001 Danger Label ................................... 1
47 940895001 E85 Label ........................................ 1
48 940896001 Homelite Inquiries Label ................. 1
49 940898001 Emc Compliance Label ................... 1
50 940899001 No Oil To Gas Label ........................ 1
51 940901001 Combustion Label ........................... 1
52 941494006 Fuel Label ........................................ 1
53 940654089 Trigger Handle Warning Label
(English) ........................................... 1
54 940654084 Warning Label
(French and Spanish) ...................... 1
55 940786006 Wand Label (Max Rating) ................ 1
56 940473002 Danger Hangtag .............................. 1
57 940517007 Lubricant Label ............................... 1
58 308862003 Outlet Tube ...................................... 1
59 308862001 Filter Screen .................................... 1
60 310606001 Vent Cap ......................................... 1
61 308452002 Detergent Suction Kit ...................... 1
62 308861003 Inlet Tube ......................................... 1
Not Shown:
987000985 Operator’s Manual...........................1
987000987 Assembly Guide ..............................1
