Homelite UT10514/14 IN. 33CC User Manual

Page 13
OPERATION
STARTING THE ENGINE
See Figures 6 - 11.
Starting the product differs depending on whether the engine
is cold or warm.
WARNING:
Keep your body to the left of the chain line. Never straddle
the saw or chain, or lean over past the chain line.
Place the chain saw on level ground and ensure that no
objects or obstructions are in the immediate vicinity that
could come in contact with the bar and chain.
 Hold the front handle firmly with your left hand and put
your right foot onto the base of the rear handle.
To start a cold engine:

Set the ignition switch to the RUN ( I ) position.

Make sure the chain brake is in the run position by pulling
back on the lever/hand guard.

Fully press and release the primer bulb 7 times.

Pull choke lever all the way out to FULL position.

While squeezing both the trigger release and throttle trig-
ger, push in the throttle lock button. Release the throttle
trigger. This latches the trigger for starting.

When the temperature is above 50°F, pull the starter
grip until the engine attempts to start, but no more than
3 times. When the temperature is below 50°F, pull the
starter grip until the engine attempts to start, but no more
than 5 times.
Fig. 6
IGNITION SWITCH
IN THE RUN
POSITION
Fig. 7
PRIMER BULB
Fig. 9
Fig. 10
FULL CHOKE
CHOKE LEVER
HALF CHOKE
RUN POSITION
Fig. 8
STARTER
GRIP
RUN
POSITION

Homelite UT10514/14 IN. 33CC Specifications

General

Engine Displacement	33 cc
Weight	12.5 lbs
Power Source	Gasoline
Bar Length	14 inches
Power Type	Gas
Chain Gauge	0.050 in
Chain Pitch	3/8 in.
