Homelite UT10640 Repair Sheet

8
HOMELITE 35cc/38cc/42cc CHAIN SAWS
MODEL NOS. UT10549, UT10569, UT10589
PARTS LIST (FIGURE D)
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 290298001 Ignition Switch Harness ............................................. 1
2 660613001 Bolt (M5 x 25.4 mm) ................................................... 2
3 309261001 Ignition Module ........................................................... 1
4 309892002 Short Block Assembly (Inc. Key Nos. 10-19) ............. 1
5 310503002 Intake Assembly (Inc. Key Nos. 20-31) ...................... 1
6 310041002 Crankshaft & Piston Assembly
(Inc. Key Nos. 12-18) .................................................. 1
7 309010003 Flywheel Assembly ..................................................... 1
8 631049001 Washer ....................................................................... 1
9 678067001 Flywheel Nut ............................................................... 1
10 660607002 Screw (M5 x 24 mm) .................................................. 4
11 640251001 Crankshaft Case ......................................................... 1
12 570090001 Crankshaft Seal .......................................................... 2
13 678048001 Ball Bearing ................................................................ 2
14 309163003 Crankshaft & Rod Assembly ...................................... 1
15 678053001 Spring Retainer ........................................................... 2
16 620579001 Piston Pin ................................................................... 1
17 309110002 Piston ......................................................................... 1
18 690161006 Piston Ring ................................................................. 2
19 640202008 Cylinder ...................................................................... 1
20 678695001 Press Plate, Cylinder .................................................. 1
21 661600001 Bolt (M5 x 14 mm) ...................................................... 2
22 570757001 Intake Boot ................................................................. 1
23 309362003 Carburetor .................................................................. 1
24 518762001 Air Filter Box ............................................................... 1
25 671080001 Washer ....................................................................... 2
26 661600002 Bolt (M5 x 50 mm) ...................................................... 2
27 518849001 Baffle .......................................................................... 1
28 678694001 Press Plate, Carb ........................................................ 1
29 638528002 Carb Bracket .............................................................. 1
30 901652001 Air Filter ...................................................................... 1
31 678603001 Throttle Rod ................................................................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
