Page 23 — English
Fig. 31
BAR GROOVE
CHAIN DRIVE LINKS
Fig. 29
CUTTERS
CHAIN ROTATION
CHAIN DRIVE LINKS
Fig. 28
Fig. 30
CAUTION:
Always wear gloves when handling the bar and
chain; these components are sharp and may
contain burrs.
BAR STUDS
CHAIN TENSIONING
PIN HOLE
CHAIN TENSIONING
KNOB
CHAIN TENSIONING
PIN
CHAIN
COVER
CHAIN COVER
LOCK KNOB
MAINTENANCE
WARNING:
Never touch or adjust the chain while the motor
is running. The saw chain is very sharp; always
wear protective gloves when performing main-
tenance to the chain to avoid possible serious
lacerations.
