Homelite UT46510 Replacement Parts List

3
PARTS LIST
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
ELECTRIC CULTIVATOR or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 33202282G Lower Handle ................................................ 1
2 3220107G Screw (M4.2 x 14 mm)................................... 6
3 34103282G Cable Retainer Ring ...................................... 2
4 3220436G Handle Bolt .................................................... 2
5 3410835G Handle Knob .................................................. 2
6 33207282G Switch plate ................................................... 1
7 34102282G Upper Cable Retainer Ring ........................... 1
8 31115282G Upper Handle Assembly................................ 1
9 3411135G Cord Retainer Ring ........................................ 1
10 38105282G Icon Warning Label ........................................ 1
11 38102282G Hang Tag ....................................................... 1
12 31105282G Front Handle Assembly ................................. 1
13 31112822G Switch Trigger Assembly ............................... 1
14 31113282G Switch Lock-out Assembly............................ 1
15 31101282G Switch Cable Assembly ................................. 1
16 3230136G Retaining Ring ............................................... 2
17 33903282G Compression Spring ...................................... 1
18 36301282G Switch ............................................................ 1
19 31104282G Switch Actuator ............................................. 1
20 31107282G Switch Box Assembly .................................... 1
21 31101281G Gear Box Assembly ....................................... 1
22 32201282G Bolt (M6 x 35 mm Hex Hd.) ........................... 4
23 3420102G Bend Relief .................................................... 1
24 3290699G Washer (M6)................................................... 4
25 32205271G Bolt (M6 x 25 mm, Hex Hd.) .......................... 4
26 31117282G Tine Shield Assembly .................................... 1
27 38103282G Foot Warning Label ....................................... 1
28 34111282G Adjustment Knob ........................................... 1
29 34105282G Motor Base .................................................... 1
30 3220343G Lock Nut (M6) ................................................ 8
31 3411435G Wire Clip ........................................................ 1
32 33206282G Flex Shaft ...................................................... 1
33 36901281G Circuit Breaker ............................................... 1
34 31118282G Lower Motor Cover ....................................... 1
35 32212100G Screw (M4 x12 mm)....................................... 1
36 33203282G Switch Cable Clip .......................................... 1
37 38106282G Data Label ..................................................... 1
38 36401281G Power Cord ................................................... 1
39 38104282G Warning Label................................................ 1
40 31116282G Upper Motor Cover ....................................... 1
41 38107282G Logo Label (right)........................................... 1
42 38101282G Logo Label (left) ............................................. 1
43 3220210G Screw (M4.2 x 18 mm)................................... 7
44 36111281G Brush Assembly ............................................ 2
45 31114282G Motor Assembly ............................................ 1
46 33209281G Flex Shaft Adaptor......................................... 1
47 3320543G Hitch Pin ........................................................ 2
48 31105281G Tine Assembly (D) .......................................... 1
49 34901282G Washer (Felt) .................................................. 2
50 31104281G Tine Assembly (C) .......................................... 1
51 31103281G Tine Assembly (B) .......................................... 1
52 31102281G Tine Assembly (A) .......................................... 1
53 3290237G Hitch Pin ........................................................ 2
54 3220898G Washer........................................................... 2
55 31102282G Wheel Assembly (6 in.) .................................. 2
56 31103282G Axle/Drag Stake Assembly ............................ 1
NOT SHOWN:
987000517 Operator’s Manual ...................................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
HOMELITE ELECTRIC CULTIVATOR – MODEL NO. UT46510

Homelite UT46510 Specifications

General

Brand	Homelite
Model	UT46510
Category	Tiller
Language	English
