Homelite VAC ATTACK II UT08042 Repair Sheet

HOMELITE VAC ATTACK II BLOWERS – MODEL NUMBERS UT08042, UT08542, UT08542A, AND UT08542B
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
BLOWER or when ordering repair parts.
1 308088001 PRIMER BULB ................................................... 1
2 760363002 SWITCH ............................................................. 1
3 900954001 CRANKCASE GASKET ...................................... 1
4 660664001 * SCREW (10-24 x 9/16 in. PAN HD.) ................... 4
5 638031001 CRANKCASE COVER ........................................
1
6 570256001 RUBBER BUMPER ............................................ 2
7 570549001 BIG BUMPER ..................................................... 1
8 308123004 FUEL TANK ASSEMBLY
(INC. KEY NOS. 55-56, 61 AND 65) .................... 1
9 650013001 BUSHING-STARTER ROPE ...............................
1
10 638032001 BAFFLE PLATE .................................................. 1
11 650023001
INNER VOLUTE SEAL ........................................ 1
12 660630002 * SCREW (10-24 x 3/4 in. TRUSS HD.) ................ 4
13 650014001 BUSHING STARTER .......................................... 1
14 900849004 STARTER ROPE .................................................
1
15 638033001 SPRING & CONTAINER ..................................... 1
16 900957001 BAFFLE GASKET ............................................... 1
17 518073001 STARTER GRIP .................................................. 1
18 518249001 INNER VOLUTE HOUSING ................................ 1
19 308134001 PULLEY ASSEMBLY .......................................... 1
20 638074001 WIRE LOOP ....................................................... 1
21 660629001 * SCREW (10-14 x 3/4 in. TORX TRUSS HD.) ...... 6
22 660667001 * SCREW (10 x 1-5/8 in. HEX HD.) ....................... 1
23 518250001 OUTER VOLUTE ................................................ 1
24 650016001 FLAT WASHER ................................................... 1
25 640858001 FAN ADAPTOR .................................................. 1
26 650017001 FLAT WASHER ................................................... 1
27 518077001 FAN .................................................................... 1
28 650018001 FAN SPACER ..................................................... 1
29 570581004 SCREEN .............................................................
1
30 660669001 * SCREW (#8 x 1/2 in. PAN HD.) .......................... 6
31 518251001 BLOWER SHROUD ............................................ 1
32 518211001 SLIDE ................................................................. 1
33 348007001 SLIDE PIN .......................................................... 1
34 518247001 TRIGGER ...........................................................
1
35 660618001 * SCREW (10-24 x 3/4 in. TORX TRUSS HD.) ...... 3
36 660730001 * LOCK NUT (3/8-24) ............................................ 1
37 518078002 DOOR ................................................................. 1
38 650026001 DOOR HINGE SHAFT ........................................
1
39 638064001 DOOR HINGE SPRING ...................................... 1
40 518066002 BLOWER KNOB ................................................. 1
41 650027001 E-RING ............................................................... 2
42 290195004 WIRING HARNESS ............................................
1
43 518229001 SCREEN COVER ............................................... 1
44 580555001 UPPER TUBE ..................................................... 1
45 580556001 LOWER NOZZLE ............................................... 1
46 348005003 CLAMP ............................................................... 1
47 650024001 LOWER HANDLE ...............................................
1
48 660676001 SCREW (TAP PAN HD.) ...................................... 2
49 580559001 SWEEPER NOZZLE ...........................................
1
50 580560001 UPPER VACUUM TUBE .................................... 1
51 580561001 LOWER VACUUM TUBE .................................... 1
52 518066001 BLOWER KNOB .................................................
1
53 900960001 LEAF BAG .......................................................... 1
54 580562001 VACUUM BAG TUBE ......................................... 1
55 308283001 FUEL FILTER KIT (INC. KEY NOS. 62-64) ......... 1
56 300758006 FUEL CAP ASSEMBLY ...................................... 1
57 940299495 DOOR LABEL (VAC ATTACK) ............................. 1
58 940647001 CHOKE LABEL .................................................. 1
59 940299493 FAN INTAKE WARNING LABEL ......................... 1
60 940642005 WARNING/STARTING LABEL ............................ 1
61 570259005 RUBBER TUBING (196.85 mm) ......................... 1
62 300759003 FUEL FILTER ...................................................... 1
63 570258003 RUBBER TUBING (114.3 mm) ........................... 1
64 690765001 WIRE CLAMP ..................................................... 1
65 580553002 FUEL TANK ........................................................ 1
66 900961003 SCREEN COVER & NETTING ASSEMBLY
(INC. KEY NOS. 29 & 43) ................................... 1
67 900955001 HEAT SHIELD ..................................................... 1
68 290218001 LEAD W/TERMINALS ........................................ 1
69 638081001 MALE TAB .......................................................... 1
983000594 OPERATOR’S MANUAL (UT08042 & UT08542)
983000781 OPERATOR’S MANUAL (UT08542A)
983000950 OPERATOR’S MANUAL (UT08542B)
983000594R REPAIR SHEET (REV:05)
12-13-06
KEY PART
NO. NUMBER DESCRIPTION QTY
