Homelite VAC ATTACK II UT08544 Repair Sheet

HOMELITE VAC ATTACK II – MODEL NUMBERS UT08544 AND UT08546
4
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
VAC ATTACK II or when ordering repair parts.
1 638081001 Male Tab .............................................................1
2 900954001 Crankcase Gasket ..............................................1
3 638031001 Crankcase Cover ................................................1
4 660664001 * Screw (10-24 X 9/16 in. Pan Hd.) .......................4
5 650017001 Flat Washer .........................................................1
6 650018001 Fan Spacer .........................................................2
7 660669001 * Screw (#8 X 1/2 in. Pan Hd.) ...............................6
8 638032002 Baffle ..................................................................1
9 900957001 Baffle Gasket ......................................................1
10 518098001 Pully ....................................................................1
11 638033001 Spring & Container .............................................1
12 650023001 Inner Volute Seal .................................................1
13 900961003 Screen Cover & Netting Assembly
(Inc. Key Nos. 32 and 33) ...................................1
14 518249001 Inner Volute Housing ..........................................1
15 650013001 Bushing - Starter Rope .......................................1
16 518073001 Starter Grip .........................................................1
17 650014001 Bushing ...............................................................1
18 900849004 Starter Rope .......................................................1
19 660618001 * Screw (10-14 x 1/2 in.) ........................................3
20 660667001 * Screw (10 X 1-5/8 in. Hex Hd.) ...........................1
21 660629001 * Screw (10-14 X 3/4 in. Torx Truss Hd.) ...............6
22 308135012 Door & Knob & E-ring Assembly
(Inc. Key Nos. 40-42) ..........................................1
23 290218001 Lead W/terminals ................................................1
24 308279003 Inner Housing & Starter Assembly
(Inc. Key Nos. 7-11, 14-18 and 26) .....................1
25 308088001 Primer Bulb .........................................................1
26 760363002 Switch .................................................................1
27 348007001 Slide Pin ..............................................................1
28 518211001 Slide ....................................................................1
29 518247001 Trigger .................................................................1
30 650016001 Flat Washer .........................................................1
31 660630002 * Screw (10-24 X 3/4 in. Truss Hd.) .......................4
32 570581004 Mesh Netting ......................................................1
33 518229001 Screen Cover ......................................................1
34 518077001 Fan ......................................................................1
35 638074001 Wire Loop ...........................................................1
36 640858001 Fan Adaptor ........................................................1
37 660730001 * Lock Nut (3/8-24) ................................................1
38 518250001 Outer Volute ........................................................1
39 650026001 Door Hinge Shaft ................................................1
40 518078002 Door ....................................................................1
41 518066002 Blower Knob .......................................................1
42 650027001 E-ring ..................................................................1
43 638064001 Door Hinge Spring ..............................................1
44 518251001 Blower Shroud ....................................................1
45 650015001 Washer ................................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
