Homelite YARD BROOM II UT08514 Repair Sheet

HOMELITE YARD BROOM II – MODEL NUMBER UT08514
6
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
YARD BROOM II
or when ordering repair parts.
PARTS LIST (
FIGURE B
)
KEY PART
KEY PART
NO. NUMBER DESCRIPTION QTY
NO. NUMBER DESCRIPTION QTY
1 300952002 Fly Wheel Assembly
...........................................
1
2 308128003 Crankcase Assembly
..........................................
1
3 290195004 Ignition & Switch Harness
..................................
1
4 308023003 Piston & Rod Assembly
......................................
1
5 660342002 * Screw (M5 X 20 mm)
..........................................
3
6
660734001 * Screw (M4 X 1.75 X 16 mm)
...............................
1
7 300748010 Muffler Assembly (Inc. Key Nos. 8-13)
...............
1
8 678046001 Insulating Washer
...............................................
1
9 678045001 Flat Washer
.........................................................
1
10
678044001 Compression Spring
...........................................
1
11
900994001 Muffler Gasket
....................................................
1
12
660673001 * Screw (10-24 Hex. Hd.)
......................................
2
13
300748013 Muffler
.................................................................
1
14
660660001 * Screw (8-32 X1.0 in.)
..........................................
2
15
850080001 Ignition Module
...................................................
1
16
640069002 Cylinder
..............................................................
1
17
900953001 Cylinder Gasket
..................................................
1
18
638133002 Throttle Cable Clip
..............................................
1
19
308192005 Short Block Assembly
(Inc. Key Nos. 2, 4, 16 and 17)
(Inc. Key Nos. 2, 4, 16 and 17)
...........................
1
20
660345001 Screw (M4)
..........................................................
1
21
590458001 Choke Lever
.......................................................
1
22
590946001 Choke Plate
........................................................
1
23
900950001 Heat Dam Gasket
...............................................
1
24
660346002 Carburetor Mounting Bolt
...................................
2
25
518087001 Heat Dam
............................................................
1
26
660662001 * Screw (10-24 X 1.11 Pan Hd.)
............................
2
27
900951004 Carburetor Gasket
..............................................
1
28
518120001 Spacer
................................................................
1
29
900711003 Gasket
................................................................
1
30
308429001 Carburetor (Walbro WYC-10)
..............................
1
31
518493001 Air Filter Box
.......................................................
1
32
678027001 * Hex Nut (10-24)
..................................................
1
33
270021002 Throttle Cable
.....................................................
1
34 308592001 Air Box Base Assembly
34 308592001 Air Box Base Assembly
(Inc. Key Nos. 20-22, 31 and also
(Inc. Key Nos. 20-22, 31 and also
Inc. Key Nos. 5, 6 and 12 On Page 2)
Inc. Key Nos. 5, 6 and 12 On Page 2)
................
1
KEY PART
KEY PART
NO. NUMBER DESCRIPTION QTY
NO. NUMBER DESCRIPTION QTY
