Homestyles 73005131 - Detailed Component and Hardware Reference; Hardware, Tools, and Materials List

Part Identification
Front Wall Panel
(WP3)
Back/Side Wall Panel
(WP1/WP2)
Base Track
(AL1-AL4)
Corner Post
(CN1)
• Power drill with Phillips
®
(#2)
or a #2 Robertson bit • Level
• Safety glasses • Rubber mallet
• 5/16" & 9/64" Drill Bit • Gloves
• Measuring Tape - Min. 16' feet (5m)
Phillips is a registered trademark of PhillipsScrew Co.
• Silicone Caulking
Tools Required
Materials Needed
7
Wall Cap
(SC1)
Hilti Kwik 3/8” x 5” Bolt (WLB) 24 pcs.
Wall Support Beams
(WSB)
• #10 x 1" Pan Head
• Vis à tête cylindrique
no 10 x 1"
• Tornillo de cabeza
achatada #10 x 1"
• #10 x 3/4"
Self Tapping
• Vis autotaraudeuse
no 10 x 3/4"
• Tornillo autorroscable
#10 x 3/4"
WL Door Jamb Brace
Door Lintel
(LT1/LT2)
