Insert a Corner Post (CN1) and a Back and Side Wall Panel
(WP1/WP2) at the rear of the platform.
Insert Wall Support Beams (WSB) into walls during assembly and
mark the location of the Wall Support Beams on the inteior of the shed
walls with a pen for reference.
3
WP1
WP2
CN1
WSB
WSB
Insert Wall Support Beams (WSB) into walls as shown and mark the location of the Wall Support Beams on the inteior of the shed
walls with a pen for reference.
WP2
WSB
WSB
WSB
WSB
WSB
WSB
WSB
WSB
WSB
WP2
WP2
WP2
WP1
WP1
WP1
WP1
WP1
WSB
Mark should be visible
2” below top of wall.
Continue adding Back and Side Wall
Panels (WP1/WP2) and Corner Post (CN1).
Snap panels together and push down into
the base track. Ensure all parts are fully seated
.
4
