DISPMODE A
(Flowmeter standard display)
Flowmeter display
F (Flow) is displayed in case the flowmeter function is worked.
t (Total flow): Integrating flow
i (Instantaneous flow): Instantaneous flow
Elapsed time for integrating flow
Integrating flow
Instantaneous flow
Display of the instantaneous flow in percentage
Select cm or mm as the unit of the overflow level at UNIT of MENU1.
Select % or Max. setting flow by ↑ key.
Select the temperature or the current output value by ↓ key.
Hold down ESC key for 2 seconds to reset the integrating flow and the
elapsed time for the integrating flow.
⇒
