12
DISPMODE A
(Standard display)
Date and time display
Main display: Numerical display of
remaining amount in percentage terms,
the distance or the level in the tank.
Graphic display of the remaining amount in the tank
Select the unit, %, m or cm by ↑ key.
Select the channel, CH1, CH2 or CH1&CH2, by ← → keys.
Select the temperature or 4-20mA the by ↓ key.
4-20mA Rising the liquid level Lowering the liquid level
Current output display
Rising/Lowering the liquid level is indicated by the arrow.
? is indicated in case the ultrasonic reflection echo
cannot be detected and measurement error happens.
