16
Averaging
(AVERAGE)
In case the ultrasonic reflection echo is not stable due
to the fluctuation of the liquid surface and etc., set
AVERAGE to the larger value.
Setting range: 1 – 30
[Caution] The larger the setting value of AVERAGE is, the slower response
speed is.
Selection of ultrasonic sensor of CH2
Select either TD1 or TD2 as the sensor for CH2.
Normally, select TD2.
Ex) TD1 is selected in case both CH1 and CH2 are
used with 1 sensor simultaneously.
Reverberation mask setting
In case the distance of the reverb signal prevent the measurement,
adjust MASK to avoid the incorrect measurement.
MASK = 30 cm (Default value)
MASK = 45 cm
MASK = 70 cm
[Caution] Dead zone from the sensor is 70 cm.
