17
Frequency setting
12
⇔
21
⇔
30
⇔
40
⇔
50
⇔
Variable
Press ESC key at Variable to set the frequency at
1kHz step from 10kHz to 60kHz.
Distance correction
Distance correction can be done from -99 to 100mm.
Inversion of 4-20 mA current output
Inversion of the output current can be done.
⇒
4mA 20mA
⇒
20mA 4mA
In case the output current is inverted, the underline is indicated
under the displayed current value.
