CONTINUED
Cleanoffanydirtandoilthathas
collected around the ignition coil.
Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a flat-tipped
screwdriver. Remove the cover on
the front cylinder bank by pulling
it straight up.
The spark plugs in your car are a
special iridium-tipped design for
longer life. The spark plugs should
be replaced according to the distance
recommendation in the maintenance
schedule.
1. 2.
3.
Spark Plugs (6-cylinder Models)
Maintenance
Replacement
321
CONNECTOR
HOLDING CLIP IGNITION COIL
０２／１１／１８ ２３：１７：５１ ３１ＳＤＰ６００ ０３２４
